smart control e-plug
with energy measurement function
art. no. 51150
Quick Start Operating Instructions
Plug
Important
Prior to using the device for the first time, carefully and completely read
through all operating instructions. A detailed user manual is ready for
download (see link below).
Simplified EU Declaration of Conformity
Hereby, stabo Elektronik GmbH declares that the radio equipment type
stabo smart control e-plug is in compliance with the Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the
following Internet address:
http://stabo.de/fileadmin/BdA/BdA_stabo_smart_control_e-plug_DE_EN.pdf
Scope of delivery
WLAN switching plug
Brief operating instructions (German/English)
Please check the contents of the package for completeness. Prior to
using the set, examine it with respect to any external damage. In case
of an external damage, do not put the product into operation, but contact
your specialist dealer immediately.
Key functions and LED status
WLAN status
slowly blinking LED: switching plug is connected to WLAN
rapidly flashing LED: configuration mode is active or
Switching key
Switching the unit on/off manually
LED lights permanently when power is on
WLAN status LED
(blue)
Reset to factory setting (pressing the key for approx. 5 sec.)
rapidly flashing LED
Switching key
(with red LED) Activating the direct mode between smart control e-plug and
smartphone (pressing the key for approx. 10 sec.)
The LED flashes rapidly, then slowly
Socket
Commissioning/initial installation
First download the iOS or Android version of the app WeConn from
the App Store or Google Play Store according to the operating system
of your mobile device. To do so, enter WeConn into the search bar,
mark the app, download and install it.
Note: In these operating instructions, all operational steps are described
for the Android version of the app.
no WLAN connection
Connecting the smart
control e-plug to the
mobile device
Plug the WLAN switching plug sup-
ply unit into a socket (230 V).
Make sure that your mobile device
is connected with your WLAN router.
Open the app WeConn.
Tap the WeConn logo, scroll to the last page of the screen and tap
Enter.
Tap the button (Einstellungen).
