7 Product illustration and controls
1
8*
7
6
5**
DE: WARNUNG！
Nicht hintereinander stecken!
Nicht abgedeckt betreiben!
Model No.: BEA28B
Nur zur Verwendung in trockenen Räumen!
Ref.: 2490493
16A 250V/AC
Max.3680W 230 V/AC 50Hz
EN: Warning!
distributed by Do not connect the product in series!
Conrad Electronic SE
Do not operate the device while covered!
Klaus-Conrad-Str. 1,
Only to be used in a dry indoor environment!
D-92240 Hirschau
* The above image shows the 5-socket power strip with item no. 2490615. Both product variants are technically identical
and differ only in the number of sockets. The socket strip with item no. 2490614 has 3 sockets, and the socket strip with
item no. 2490615 has 5 sockets.
* * The sticker with safety and additional information (5) is only shown as an example and may differ from the delivered
product.
1 USB-A and USB-C 4 Recesses for wall
TM
quick charging ports mounting
2 Protective contact plug 5 Sticker with safety and
additional information
3 Cable
6 Main switch
Both product variants have USB overcurrent, over-temperature and short-circuit protection for
enhanced safety.
8 Operation
Before use, read the safety instructions in the Safety section.
Notes:
– For plugs < 20 mm, first lock the socket (8) by hand and then plug in.
– Remove the plug by pulling it out and then unlock the socket (8) by hand.
1. Insert the protective contact plug (2) into an earthed mains socket.
2. Use the sockets (8) and the USB-A and USB-CTM quick charging ports (1) for electrical
devices.
3. To eject protective contact plugs, simply press on the respective plug.
4. Press the main switch (6) to switch all sockets (8) and quick charging ports (1) on/off.
9 Cleaning and care
Important:
– Do not use any aggressive cleaning agents, rubbing alcohol or other chemical
solutions. These may damage the housing and can cause the product to malfunction.
– Do not use liquids, wet cloths, sponges or other damp objects to clean the product.
– Never expose the product to moisture.
– Keep the product free from dust.
NL: Waarschuwing!
Niet in serie schakelen!
Niet afgedekt gebruiken!
Alleen gebruiken in droge ruimten!
IT: Avvertenza!
Non inserire l'una dopo l'altra!
Non maneggiare se scoperta!
Wxx
Solo per l'uso in ambien� asciu�! 21
4
7 Plastic casing
8 Sockets with enhanced
protection against
accidental contact
1. Disconnect the protective contact plug (2) from the socket. This disconnects the product
from the voltage supply.
2. Unplug all devices from the sockets (7) and quick charging ports (1).
3. Use a vacuum cleaner to remove dust from the product.
2
10 Disposal
This symbol must appear on any electrical and electronic equipment placed on the
EU market. This symbol indicates that this device should not be disposed of as
unsorted municipal waste at the end of its service life.
Owners of WEEE (Waste from Electrical and Electronic Equipment) shall dispose
of it separately from unsorted municipal waste. Spent batteries and accumulators,
which are not enclosed by the WEEE, as well as lamps that can be removed from
the WEEE in a non-destructive manner, must be removed by end users from the
WEEE in a non-destructive manner before it is handed over to a collection point.
Distributors of electrical and electronic equipment are legally obliged to provide free take-back
of waste. Conrad provides the following return options free of charge (more details on our
website):
3
in our Conrad offices
at the Conrad collection points
at the collection points of public waste management authorities or the collection points set
up by manufacturers or distributors within the meaning of the ElektroG
End users are responsible for deleting personal data from the WEEE to be disposed of.
It should be noted that different obligations about the return or recycling of WEEE may apply in
countries outside of Germany.

11 Technical data

11.1 Information according to Regulation 2019/1782
Address
Commercial Registration Number
Model identifier
Input voltage
Input AC frequency
Output voltage
Output current
Output power
Average active efficiency
Efficiency at low load (10 %)
No-load power consumption
Efficiency at low load (10 %)
No load power consumption
11.2 Miscellaneous
Total connected load ...................................Max. 3680 W
Cable length ...............................................1.5 m
Cable type ..................................................H05VV-F 3G, 1.5 mm²
Operating temperature ...............................0 °C to +40 °C
Operating humidity .....................................0 - 85 % RH (non-condensing)
Storage temperature ...................................-20 °C to +70 °C
Storage humidity .........................................0 - 95 % RH (non-condensing)
Dimensions (LxWxH) .................................. 278 × 60 × 51 mm (item no. 2490614)
Weight ........................................................ 612 g (item no. 2490614)
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method (e.g. photocopying, microfilming or capturing in
electronic data processing systems) requires prior written approval from the publisher. Reprinting, also in part, is
prohibited. This publication reflects the technical status at the time of printing.
Copyright 2022 by Conrad Electronic SE.
Conrad Electronic SE, Klaus-Conrad-Str. 1, 92240
Hirschau, Germany
HRB 3896
BEA35B (2490614) / BEC22B (2490615)
230 V/AC
50 Hz
USB-A 1:
5.0 V/DC 3.0 A Max.15.0 W
9.0 V/DC 2.0 A Max.18.0 W
12.0 V/DC 1.5 A Max.18.0 W
USB-C 1:
®
5.0 V/DC 3.0 A Max.15.0 W
9.0 V/DC 2.0 A Max.18.0 W
12.0 V/DC 1.5 A Max.18.0 W
USB-A 1 +USB-C 1:
®
5.0 V/DC 3.4 A, Max.17.0 W
84.2 %
72.6 %
0.07 W
72.5 %
0.07 W
380 × 60 × 51 mm (item no. 2490615)
800 g (item no. 2490615)
