Operating Instructions
HC-2 DIGITAL HAND COUNTER
Item No. 101030
1 Intended use
This product is designed to manually record and digitally display quantities. The value can be increased
or decreased by the press of a button. The product is suitable for counting goods or produced items, for
example, or to record the number of visitors to a venue or event. Power is supplied via a CR1616 type
button cell battery.
This product complies with the statutory national and European requirements. All company names and pro-
duct names are trademarks of their respective owners. All rights reserved.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use the product
for purposes other than those described above, the product may be damaged. In addition, improper use can
cause hazards such as short circuiting, fire, electric shock etc. Read the instructions carefully and keep them.
Make this product available to third parties only together with its operating instructions.
2 Delivery content
Hand counter
Neck strap
3 Safety instructions
Read the operating instructions care-
fully and especially observe the safety
information. If you do not follow the
safety instructions and information on
proper handling in this manual, we
assume no liability for any resulting
personal injury or damage to property.
Such cases will invalidate the warranty/
guarantee.
3.1 Persons / Product
The device is not a toy. Keep it out of the reach
of children and pets.
Do not leave packaging material lying around
carelessly. These may become dangerous
playing material for children.
Protect the product from extreme temperatu-
res, direct sunlight, strong jolts, high humidity,
moisture, flammable gases, vapours and sol-
vents.
Do not place the product under any mechanical
stress.
If it is no longer possible to operate the product
safely, take it out of operation and protect it
from any accidental use. Safe operation can no
longer be guaranteed if the product:
– is visibly damaged,
– is no longer working properly,
– has been stored for extended periods in
poor ambient conditions or
– has been subjected to any serious trans-
port-related stresses.
Please handle the product carefully. Jolts,
impacts or a fall even from a low height can
damage the product.
4 Operating elements
1
2
Button cell, type CR1616
Operating instructions
3.2 Batteries / Rechargeable batteries
Correct polarity must be observed while inser-
ting the batteries.
Batteries should be removed from the device if
it is not used for a long period of time to avoid
damage through leaking. Leaking or damaged
batteries might cause acid burns when in con-
tact with skin, therefore use suitable protective
gloves to handle corrupted batteries.
Batteries must be kept out of reach of children.
Do not leave the battery lying around, as there
is risk, that children or pets swallow it.
All the batteries should be replaced at the
same time. Mixing old and new batteries in the
device can lead to battery leakage and device
damage.
Batteries must not be dismantled, short-
circuited or thrown into fire. Never recharge
non-rechargeable batteries. There is a risk of
explosion.
3.3 Miscellaneous
Consult an expert when in doubt about operati-
on, safety or connection of the device.
Maintenance, modifications and repairs are to
be performed exclusively by an expert or at a
qualified shop.
If you are not sure about the correct connection or
use, or if questions arise which are not covered by
these operating instructions, please do not hesitate
to contact our technical support or another qualified
specialist.
3
4
5
6
1 Battery compartment
2 Button ↓
3 Backlight
4 Button ↑
5 Display
6 On/off/reset button
5 Inserting / replacing batteries
1. Turn the battery compartment cover counter-
clockwise using a tool (such as a coin) and
remove the cover.
2. Insert a type CR1616 button cell battery obser-
ving the correct polarity. The positive end must
point outwards.
3. Put the cover on again and turn it clockwise to
close the battery compartment.
Replace the battery when the digits on the
display become faint or are no longer dis-
played at all.
6 Operation
6.1 General information
1. Hold the on/off/reset button down for approx. 2
seconds to turn the device on/off.
2. Press the ↑ button to increase the value shown
on the display by 1.
3. Press the ↓ button to decrease the value
shown on the display by 1.
4. Press the reset button to reset the display va-
lue to 0.
5. Press and hold the backlight button to activate
the display light.
6.2 Automatic off function
1. The device powers off after five minutes of
inactivity. To display the last counter reading
again, press the ↑ or ↓ button.
8 Disposal
8.1 Product
This symbol must appear on any elec-
trical and electronic equipment placed
on the EU market. This symbol indica-
tes that this device should not be dis-
posed of as unsorted municipal waste
at the end of its service life.
Owners of WEEE (Waste from Elec-
trical and Electronic Equipment) shall
dispose of it separately from unsorted
municipal waste. Spent batteries and
accumulators, which are not enclosed
by the WEEE, as well as lamps that
can be removed from the WEEE in a
non-destructive manner, must be re-
moved by end users from the WEEE
in a non-destructive manner before it is
handed over to a collection point.
Distributors of electrical and electronic equipment
are legally obliged to provide free take-back of
waste. Conrad provides the following return options
free of charge (more details on our website):
in our Conrad offices
at the Conrad collection points
at the collection points of public waste manage-
ment authorities or the collection points set up
by manufacturers or distributors within the me-
aning of the ElektroG
End users are responsible for deleting personal
data from the WEEE to be disposed of.
9 Technical data
Operating voltage .................... 1 x 3 V/DC lithium button cell, type CR1616
Display ..................................... 4 digits
Dimensions (W x H x D) .......... 58 x 69 x 23 mm
Weight ..................................... 38 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights in-
cluding translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represents the technical status at the time of printing.
Copyright 2022 by Conrad Electronic SE.
2. To deactivate the automatic off function, press
and hold the ↑ button for approx. three seconds
during operation. The clock icon on the left side
of the display goes off.
3. To activate the automatic off function, press
and hold the ↑ button for approx. three seconds
during operation. The clock icon appears on
the left side of the display.
6.3 Signal sound
1. Each time a counter button is pressed, a signal
tone sounds.
2. To deactivate the signal sound function, press
and hold the ↓ button for approx. three seconds
during operation. The crossed-out bell icon ap-
pears on the left side of the display.
3. To activate the signal sound function, press
and hold the ↓ button for approx. three seconds
during operation. The bell icon appears on the
left side of the display.
7 Maintenance and cleaning
No maintenance is necessary for the device apart
for occasional cleaning and the changing of the
battery.
Clean the exterior of the device with a soft, dry cloth
or brush only.
Never use aggressive or chemical cleaning agents,
since this might damage the surface of the housing
or impair operation.
It should be noted that different obligations about
the return or recycling of WEEE may apply in coun-
tries outside of Germany.
8.2 (Rechargeable) batteries
Remove batteries/rechargeable batteries, if any,
and dispose of them separately from the product.
According to the Battery Directive, end users are
legally obliged to return all spent batteries/rechar-
geable batteries; they must not be disposed of in
the normal household waste.
Batteries/rechargeable batteries con-
taining hazardous substances are
labelled with this symbol to indicate
that disposal in household waste is
forbidden. The abbreviations for heavy
metals in batteries are: Cd = Cadmi-
um, Hg = Mercury, Pb = Lead (name
on (rechargeable) batteries, e.g. below
the trash icon on the left).
Used (rechargeable) batteries can be returned to
collection points in your municipality, our stores or
wherever (rechargeable) batteries are sold. You
thus fulfil your statutory obligations and contribute
to environmental protection.
Batteries/rechargeable batteries that are disposed
of should be protected against short circuit and their
exposed terminals should be covered completely
with insulating tape before disposal. Even empty
batteries/rechargeable batteries can contain residu-
al energy that may cause them to swell, burst, catch
fire or explode in the event of a short circuit.
*101030_V3_0522_02_jh_m_en
