Teileliste Rückfahrkamera Signal / Stromkabel Spannmutter...
Seite 5
Einbauanleitung 1. Prüfen Sie vor der Installation der Kamera, ob diese vollständig ist und ordnungsgemäß funktioniert. Wählen Sie den gewünschten Montageort. Platzieren Sie die Kamera am zukünftigen Montageort und prüfen Sie, ob der Blickwinkel von diesem Ort für Sie geeignet ist. 2.
Seite 6
6 mm 6 mm 4. Wenn Sie das gewünschte Loch ausgesucht oder gebohrt haben, stecken Sie den Verbindungsstecker durch das Loch in das Fahrzeug. Bitte dichten Sie den Kabelkanal sorgfältig mit einer geeigneten Karosseriedichtmasse ab, um ein Eindringen von Wasser in den Fahrzeuginnenraum zu verhindern.
Seite 7
5. Sichern Sie die Kamera mit einer Spannmutter und achten Sie darauf, dass das Dichtmittel und die Kabeldichtung bei der Montage nicht beschädigt werden. Dichten Sie ggf. von innen ab. Verbinden Sie anschließend den Stecker der Kamera mit dem Signal / Stromkabel.
Parts list Rear view camera Signal / Power cable Clamping nut...
Seite 13
Einbauanleitung 1. Before installing the camera, check that it is complete and working properly. Select the desired mounting location. Place the camera at the future mounting location and check if the viewing angle from this location is suitable for you. 2.
Seite 14
6 mm 6 mm 4. When you have selected or drilled the desired hole, insert the connector plug through the hole into the vehicle. Please seal the cable duct carefully with a suitable body sealant to prevent water from entering the vehicle interior.
Seite 15
Secure the camera with a clamping nut and make sure that the sealant and the cable seal are not damaged during assembly. Seal from the inside if necessary. Then connect the plug of the camera to the signal / power cable.
Seite 20
NEOTONE kontaktieren Wenn Sie Fragen oder Anmerkungen zu NEOTONE-Produkten haben, wenden Sie sich bitte an den NEOTONE-Kundendienst. Land Kundenservice Website Adresse NEOTONE GmbH www.neotone.de/ DEUTSCHLAND +49 (30) 260-782-10 Alt-Moabit 42, support/ 10555 Berlin Kontaktinformationen zur Barrierefreiheit in Deutschland: info@neotone.de www.neotone.de...
