RESETTING DUAL CLUTCH SYSTEM
Press and hold the left gear shift, right gear shift, and square
button for two seconds.
The RPM LEDs will all flash four times and then extinguish
to indicate that the Dual Clutch system has been reset.
The button assigned to the Dual Clutch system (L3 or R3)
will revert to its normal function.
USING LOGITECH G HUB
Logitech G HUB enables the following features on the G923:
• Button programming with profiles that can be linked
to games.
• Adjustment of wheel settings, such as Rotation Angle
and TRUEFORCE strength.
• Testing of the various buttons, wheel and pedal functions.
G HUB WHEEL SETTINGS
Sensitivity
Alters the output response of the wheel to be more or less
sensitive. Leaving this slider at 50% will provide a linear 1:1
output. Between 51% and 100% will make the wheel increasingly
more sensitive around the center movement of the wheel.
Between 0% and 49% will make the wheel decreasingly sensitive
around the center movement of the wheel.
Operating Range
The G923 is capable of up to 900 degrees of rotation. Reducing
this setting will change the point at which the wheel will reach
full steering lock. This is especially useful if you're driving a car
with a smaller actual steering lock angle, such as a Formula 1
or GT3 car.
Centering Spring (for games without force feedback)
Most games that support force feedback already model
the correct return to center function of the G923 based on
the virtual car. It is recommended that the Centering Spring
option be turned off for these games.
Enabling the Centering Spring option will allow you to override
the game features and adjust the strength of the return
to center force using the provided slider.
Torque
Only available for TRUEFORCE supported games. Torque controls
the overall force feedback strength for your G923.
