Modula MOCSRR0AC011 cm 124 Montageanleitung

VOLVO V70
MOCSRR0AC011 cm 124
MOCSRR0AL007 cm 124
1 - L1148/1 ant. sx
1 - L1148/2 ant.dx
2 - L1081 post.
4 - RC1500/45
8 - RCVM6X9Q
2 - RCVM6X12Q
4 - RC20200026
1 - RCBR5
1 - RCBR4
! ! !
12 11 10 9 8 7 6 5 4 3 2 1
4 Nm
I-montare la
barra anteriore.
GB- t the front bar.
E- ajustar la
barra frontal.
model 2007
I-montare le guarnizioni
GB- t the gaskets
E- montar las juntas
L1148/1
L1148/2
9 mm
12 mm
L1081
10
anteriore, avant, front,
vorne, delantera
MOCSRR0AC011 cm 124
MOCSRR0AL007 cm 124
L1148/1
MOCSKT 119
max
Kg. 60
I-montare gli attacchi
GB- t the clamps
E- ajustar las pletinas
9mm
10
1 2 3 4 5 6 7 8 9 10 11 12
L1148/2
L2
4 Nm
