Quick Installation Guide
System Requirements
1. Expansion Slot: Motherboard with one or more
PCI Express x16 slot.
2. Display: Monitor or other display device with
compatible connectivity to the output interface of
your graphics card.
3. Power requirement: Power Consumption differs
by model.
(For additional support details, please refer to:
www.powercolor.com/ to calculate your minimum
system power requirement.)
4. Operation System: Linux©/Windows
Windows 11
®
(For additional support details, please refer to:
https://www.amd.com/en/support)
5. Optical Driver Device (for CD installation)
Hardware Installation
Turn off computer, switch off the PSU, and
1
disconnect the power cord.
2
Open the case.
Remove any existing graphics card (if applicable)
3
or PCIE slot covers.
4 Insert the Graphics Card into the PCIE slot.
Make sure seating is secured with the PCIE
5
locking mechanism in place.
6 Secure graphics card to the PCIE bracket with
thumbscrew.
7 Plug in the required external PCIE power
connectors (if applicable) from the appropriate
PC Power Supply Unit.
8
Close the case.
9 Connect the display cable into the corresponding
GPU display output port.
10 Power on System, booting to OS. (Removing all
drivers for your previous card and performing a
clean install of the new drivers is recommended.)
Driver Installation
1. Please download the driver.
2. Install the driver based on your product.
3. Execute the driver and follow the instruction.
Driver Installation Link
Driver for PowerColor
https://www.powercolor.com/downloads
Driver and Support for AMD
https://www.amd.com/en/support
Additional Support
A
1. If the graphics card has multiple BIOS
10/ 2. LED Switch (Optional)
®
B
AMD Radeon Setting Software Installation
To take full advantage of the features and
capabilities of your Radeon Graphics products,
installing the most up-to-date Radeon Software is
recommended.
(For more support, visit: https://www.amd.com/en/
support/driverhelp)
*Please make sure you choose "Full Install" when
installing the driver to enjoy full function of the
software.
5
switches, you can switch to your personal
preference.
a. Confirm that the computer is powered off
and switch the BIOS you want.
b. Reboot your PC.
(For additional support details, please refer
to:https://www.powercolor.com/ for specific
model support)
(If the product is equipped with a LED switch,
users can switch to ON/OFF or different color
according to personal needs.)
TYPE 1 : color 1/ OFF
TYPE 2 : color 1/ OFF /color 2
(Please check on the following URL to see
which type of switch is on your card :
https://www.powercolor.com/)
