ASSEMBLY INSTRUCTIONS
Step 1

Leg Press Frame (10)

A) Fix the Front Base Tube (9) to the Front Upright Frame (8) with Carriage Bolts (13),
Arc Washers (14) and Cap Nuts (15).
B) Connect the Front Upright Frame (8) and the Main Frame (1) with Internal Hex Cap
C) Install the Adjustment Knob (24) on the Front Upright Frame (8).
D) Fix the Leg Press Frame (10) to the Front Upright Frame (8) with Internal Hex Cap
Screw (18), Flat Washers (20) and Nylon Lock Nut (22). Insert the Ball
Lock Pin with Grip Handle (23) to the appropriate hole.
If you find the Leg Press Frame difficult to move around, loosen Nylon Lock Nut (22)
a little bit.
Main Frame (1)

Front Upright Frame (8)

Front Base Tube (9)
