Before Assembly - Finer Form FF-TB011384 Bedienungsanleitung

HARDWARE LIST
Part 13 Part 14
Part 17 Part 18
Flat Washer D8 x10
Part 21
Part 20
Flat Washer D10 x12
Part 24
Part 25
Adjustment Knob x1
Part 28
Fork Wrench x1
!
We recommend you to tighten all screws after all steps are done, instead of tightening
Part 15
Arc Washer x2
Part 19-1
Internal Hex Cap
Part 22
Internal Hex Cap
Screw M10*115 x2
Hex Wrench 5mm x1
Plug x4

BEFORE ASSEMBLY

screws at every step.
Cap Nut M8 x2
Part 19-2
Internal Hex Cap
Part 23
Nylon Lock Nut M10 X7
Part 27
5
Internal Hex Cap
Screw M10*70 x2
Internal Hex Cap
Screw M8*35 x4
Ball Lock Pin with
Grip Handle x1
