LUM 22 HR 10
Lubrication
Lubricate specially gears, valve and clutch with grease containing
molybdenum disulphide (e.g. Molykote BR2 Plus). Please see
exploded views and fig. under Service instructions.
Lubricate o-rings and threaded connections with grease before
assembling.
Oil (ambient tempera-
Brand ture: +10
BP Energol RD-E46
Castrol
Esso/Statoil Arox EP 68
Kuwait Petroleum Q8 Chopin 46
Mobil Almo Oil 525
Shell Torcula68/Torcula32
Texaco RD Lube 32
Molykote
Spare parts
Parts without ordering number are for technical reasons not delivered
separately.
The use of other than genuine Atlas Copco replacement parts may
result in decreased tool performance and increased maintenance and
may, at the company option, invalidate all warranties.
o o
C - +30 C) Grease
Energrease LS-EP2
Spheerol SW 2 EP
Beacon EP2
Q8 Rembrandt EP2
Mobilplex 48
Alvania Grease EP2
Multifak EP2
BR2 Plus
Atlas Copco Tools – No. 9836 2017 00

Service Kits

Even the best tool needs maintenance and overhaul. Continous
industrial use in tough working environments wear out some parts.
Before a tool breaks down it loses power and becomes less
productive. A gradual change can be difficult to detect. Atlas Copco
Service Kits will give new life to your tool.
Everything you need to recondition your tool is contained in just one
Kit. Instead of replacing an individual part i.e vanes, as they wear out,
recondition the entire tool with an Atlas Copco Tools Service Kit. This
will guarantee a good function of your tool and added assurance of
dependability.
Service tools
The service tools which should be used to facilitate rational and fast
overhauling are listed in figures and in the exploded views.
Service boards and service tool sets
Besides the recommended service tools, for this specific machine, we
can offer complete service boards with service tool sets.
As optional equipment we can also offer a "Board cabinet" which suits
the Service Boards.
Boards and cabinet are in a yellow colour. The size of the boards is
980x960x1.5mm.The boards are equipped with tool holders,
transparent film with black silhouettes of the service tools (brackets to
assemble the boards on the wall incl.)
For more information please read Atlas Copco Service News
concerning Service boards and tools, Ordering No. 9835 5483 00.
Useful information
Log in to Atlas Copco WEB site: www.atlascopco.com
You can find all kind of information concerning Atlas Copco Tools
products, accessories, spare parts, published matters on our WEB
site.
ENGLISH – Instructions
