Seite 1: Operators Manual
QUICK & CRASH OPERATORS MANUAL T IS THE RESPONSIBILITY OF THE OPERATOR TO MAINTAIN CUSTOMER SAFETY AT ALL TIMES AND IT IS IMPERATIVE THAT THE DETAILS SET OUT IN THIS MANUAL ARE FOLLOWED PRECISELY Issue 1 Part No. 90500074...
Seite 2: Inhaltsverzeichnis
Contents OPERATORS MANUAL ..........................1 GENERAL SAFETY CONSIDERATIONS ....................4 ALLGEMEINE SICHERHEITSHINWEISE ....................6 GENERELLE SIKKERHEDSOVERVEJELSER ..................8 CONSIDERACIONES GENERALES DE SEGURIDAD................10 CONSIGNES GENERALES DE SECURITE .................... 12 ΕΞΕΤΑΣΗ ΓΕΝΙΚΗΣ ΑΣΦΑΛΕΙΑΣ ......................14 CONSIDERAZIONI GENERALI SULLA SICUREZZA ................16 VANLIGE SIKKERHETSTILTAK .......................
Seite 3 7. MAINTENANCE ..........................46 Regular Cleaning ........................48 7-1-1 Cleaning the Glasses and Half Mirror................48 7-1-2 Cleaning the Flat Target Sensor Assy .................. 48 7-1-3 Cleaning the Cup Target Sensor ..................49 7-1-4 Cleaning the Gun Lens ......................50 7-1-5 Cleaning the Fibre Optic Cable ....................
Seite 4: Safety Warning
This equipment is for indoor use only and should only be used for the purpose intended. Namco Europe Ltd. bears no responsibility for accidents, injury or damage resulting from unauthorized changes to, or improper use of this equipment.
Seite 5: Moving The Equipment
Do not make any alteration to this equipment without prior approval. Doing so could cause unforeseeable danger. Only parts specified by Namco Europe Ltd. should be used when replacing parts. (Including screws) Ensure that the power to the equipment is turned OFF before commencing any maintenance work.
Seite 6: Allgemeine Sicherheitshinweise
(Suchsysteme), die Weitergabe oder sonstiges Kopieren für den gewerblichen und privaten Gebrauch sind untersagt und bedürfen der vorherigen Genehmigung durch NAMCO EUROPE LIMITED. Die informationen in diesem Handbuch entsprechen den Tatsachen bei Drucklegung. NAMCO EUROPE LIMITED behält sich jedoch das Recht zu Änderungen ohne vorherige Bekanntgabe vor.
Seite 7: Aus- Und Einbau Von Komponenten Und Teilen
Es dürfen keierlei Veränderungen ohne vorherige Genehmigung am Gerät vorgenommen werden. Zuwiderhandlungen stellen eine Gefahrenquelle dar. Für die Repartur dürfen nur Originalersatzteile (incl. Schrauben) von NAMCO EUROPE LTD. verwendet werden. Vor Beginn aller Wartungsarbeiten (Fehlersuche, Reparaturen etc.) muß der Netzstecker gezogen werden.
Seite 8: Generelle Sikkerhedsovervejelser
Denne rnaskine er kun til indendørs brug og bør kun bruges til det beregnede formål. Namco Ltd. bærer intet ansvar for ulykker eller skader som er et resultat af uautoriserede ændringer eller fejlagtig brug af denne rnaskine.
Seite 9 Justeringer eller vedligehold af denne maskine bør kun udføres af kvalificeret personale. Skift ikke noget på maskinen uden godkendelse, det kan føre til uforudset fare. Der bør kun bruges dele specificeret af Namco Europe Limited når der skiftes eller repareres dele (inklusiv skruer).
Seite 10: Consideraciones Generales De Seguridad
NAMCO EUROPE LIMITED. Si bien la información contenida en este manual se da de buena fe y es correcta en el momento de su impresión, NAMCO EUROPE LIMITED se reserva el derecho de hacer cambios y alteraciones sin previo aviso.
Seite 11 No realice alteraciones en esta máquina sin aprobación previa. De hacerlo así, pueden causar peligros imprevisibles. Sólo deben usarse las partes especificadas por Namco Europe Ltd. para reparaciones o reemplazos (incluidos los tornillos). Asegúrese de que la máquina está desconectada antes de comenzar cualquier trabajo de mantenimiento (reparaciones, resolución de problemas, etc.)
Seite 12: Mesures De Securite
Malgré le fait que les informations contenues dans ce manuel soient données de bonne foi et étaient actualisées au moment de leur impression, NAMCO EUROPE LIMITED se réserve le droit de procéder à des changements ou à des modifications sans avis préliminaire.
Seite 13 Ne pas apporter de modifications sur cette machine sans autorisation préalable, faute de quoi cela pourrait entraîner un danger. Seules les pièces détachées Namco Europe Ltd. doivent être utilsées pour le remplacement ou la réparation de pièces (y compris les vis) S’assurer que l’interrupteur soit sor OFF avant de commencer tout travail de maintenance...
Seite 14: Οδηγιεσ Ασφαλειασ
μέσο , ή με μορφή φωνητικής ηχογράφησης και ούτε να αποθηκευτεί με επανορθωτικ σύστημα , να μεταδοθεί ή να αντιγραφεί για δημ σια ή ιδιωτική χρήση , χωρίς την άδεια της NAMCO EUROPE LIMITED. Καθώς αυτές οι πληροφορίες σε αυτ το εγχειρίδιο έχουν δοθεί με καλή πίστη και ακριβώς την ώρα της τύπωσης , η...
Seite 15 ΣΗΜΕΙΩΣΕΙΣ ΓΙΑ ΤΗΝ ΕΓΚΑΤΑΣΤΑΣΗ ΠΟΤΕ να μην αν βει το μηχ νημα ε ν δεν χει Maintenance Zone ολοκληρωθε η εγκατ σταση. 76cm 100cm 100cm Για την αποφυγ ηλεκτρικ ν σοκ πρ πει το μηχ νημα να χει γειωθε . Για...
Seite 16: Considerazioni Generali Sulla Sicurezza
Quest macchina deve essere usata solo in interni e deve essere usata solo per gli scopi per cui è progettata. Namco Europe Ltd non si assume responsabilità per incidenti, ferite o damni risultanti da cambiamenti non autorizzati o da uso improprio della macchina.
Seite 17 Quando si rimpiazza o si riparano delle parti (incluse le viti) si possono usare solo parti approvate dalla Namco Europe Ltd. Assicurarsi che la macchina sia SPENTA prima di incominciare qualsiasi lavoro di manutenzione (guasti, riparazioni etc.) Se state per iniziare un lavoro non descritto in questo manuale, contattate il vostro distributore per instruzioni poichè...
Seite 18: Vanlige Sikkerhetstiltak
NAMCO EUROPE LIMITED. Da informasjonen i denne manualen er gitt i god tru og var korrekt da den ble utgitt, tillegger NAMCO EUROP LIMITED seg retten til å lage forandringer uten varsel.
Seite 19 Ikke lag noen forandringer på denne maskinen uten godkjenning. Dette kan medføre uforutsette farer. Bare deler spesifisert av Namco Europe Ltd. skal benyttes ved utskifting eller reparasjon av deler (dette gjelder også skruer). Forsikre deg om at strømmen er slått av før du påbegynner noe som helst vedlikeholdsarbeid (feilsøking, reparasjon osv.)
Seite 20: Algemene Veiligheidsoverwegingen
Deze machine is alleen bedoeld voor gebruik binnenshuis en dient alleen gebruikt te worden voor bedoelde doeleinden. Namco Ltd. is niet verantwoordelijk voor ongelukken, letsel of schade die voortkomt uit ongeoorloofde veranderingen aan of onjuist gebruik van deze machine.
Seite 21 Maak geen veranderingen aan deze machine zonder goedkeuring vooraf. Dit kan onvoorzien gevaar opleveren. Alleen onderdelen die door Namco Europe Ltd. zijn gespecificeerd dienen gebruikt te worden bij het vervangen of repareren van onderdelen (incl. schroeven). Zorg ervoor dat de machine UITgeschakeld is voordat er enig onderhoudswerk wordt verricht (troubleshooting, reparaties etc.)
Seite 22: Avisos De Segurança
NAMCO EUROPA LIMITADA. A informação contida neste manual foi fornecida de boa fé, sendo rigorosa na altura da sua publicação. A NAMCO EUROPA LIMITADA, reserva-se o direito de proceder a mudanças e alterações sem qualquer aviso prévio.
Seite 23 A substituição ou reparação de peças deverá ser feita apenas com peças de origem ou especificadas pela “Namco Europa Ltd.” (incluindo parafusos) Certifique-se que a maquina se encontra desligada sempre que iniciar qualquer tipo de trabalho de manutenção.
Seite 24: Säkerhetsanvisningar
återvinningssystem, översändas eller på annat sätt kopieras för offentlig eller privat användning, utan tillstånd från NAMCO EUROPE LIMITED. Eftersom informationen i denna manual lämnas ut i god tro och var korrekt när den trycktes, reserverar sig NAMCO EUROPE LIMITED för ändringar.
Seite 25 Gör inga ändringar på denna maskin utan ett godkännande i förväg. Detta kan förorsaka oförutsägbar fara. Endast delar som är specificerade av Namco Europe Ltd. ska användas vid utbyten eller reparation av delar (inklusive skruvar). Försäkra dig om att strömmen är avstängd innan underhållsarbete påbörjas (felsökning, reparationer etc.)
Seite 26: Turvallisuusohjeet
Tästä julkaisusta ei saa ottaa missään muodossa kopioita yksityis- tai julkiseen käyttöön ilman NAMCO EUROPE LIMITED:in lupaa. Tässä ohjekirjassa olevat tiedot pitävät julkaisuhetkellä paikkansa. NAMCO EUROPE LIMITED:illä on kuitenkin oikeus muutoksiin ilman erillistä ilmoitusta. Tämä laite on valmistettu EC direktiivien mukaisesti. Se on testattu ja todettu noudattavan seuraavia direktiivejä: 89/336/EEC ja 72/23/EEC (EN55014-1, EN55014-2 ja EN 60335 standardit).
Seite 27 Tälle laitteelle ei saa tehdä mitään hyväksymättömiä muutoksia. Se voi aiheuttaa ennalta- arvaamattomia vaaroja. Vain Namco Europe Ltd:n määrittelemiä varaosia saa käyttää vaihtaessasi tai korjatessasi osia. (sisältäen ruuvit). Varmista, että laite on kytketty POIS PÄÄLTÄ ennen työn aloittamista.
Seite 28: Specifications
1. SPECIFICATIONS POWER REQUIREMENTS:- 230v / 180watts AC AMBIENT OPERATING +5°C to +25°C TEMPERATURE:- COIN ACCEPTOR:- Mars CashFlow - Single Channel DIMENSIONS:- Assembled 760(w) x 2,430(d) x 2,050(h) Gun Cabinet 550(w) x 1,670(d) x 930(h) Target Cabinet 760(w) x 1,000(d) x 1,670(h) Header Assembly 720(w) 180(d) x...
Seite 29: How To Play
2. HOW TO PLAY Game Description This game is a “Quick Draw Shooting Game” where the player draws a gun, aims at the targets that appear and tries to hit the targets as quickly as possible. A target appears as soon as the gun is drawn from the holster and the player tries to complete the four stages (level 1 to level 4) in the shortest possible time.
Seite 30: Major Components
3. MAJOR COMPONENTS Signboard Assy Dot matrix display Rear fluorescent tubes Front fluorescent tube Flat target (U) Assy Time display 7 segment PC board Flat target (L) Assy Top cover Gun Assy [SET] lamp Shutter Assy Instruction panel [START] lamp Target Cabinet Castor Gun Cabinet...
Seite 31: Moving The Machine
4. MOVING THE MACHINE This equipment is fitted with castors to make it easier to move. Take care when moving the equipment on an inclined floor. The overall height of this equipment is 2050mm. Take care of any overhead obstructions. (e.g. Light Fittings, Electric Cables etc.) 5.
Seite 32: Das Gerät Darf An Folgenden Plätzen Nicht Aufgestellt Werden
This machine is designed for INDOOR USE ONLY. Do not install in the following places. Outdoors Direct Sunlight, places with excessive humidity or dust, places where there is water leakage, near air-conditioning or heating equipment, places with excessive heat or cold temperature. Places where it would be in the way of emergency exits or fire extinguishing equipment.
Seite 33 CETTE MACHINE EST DESTINEE UNIQUEMENT A UN USAGE INTERIEUR NE PAS INSTALLER LA MACHINE DANS LES ENDROITS SUIVANTS A l’extérieur. Directement exposée au soleil, aux endroits excessivement humides ou poussiéreux, aux endroits où il y a des risques de fuite d’eau, près de ventilateurs ou source de chaleur, aux endroits très chauds ou froids.
Seite 34 ESTA MAQUINA FOI CONCEBIDA PARA UTILIZAÇÃO EM ESPACOS INTERIORES APENAS NÃO INSTALAR A MAQUINAS NOS SEGUINTES LOCAIS:- Exteriores. `Luz solar directa, locais com humidade excessiva ou pó, locais aonde existam fugas de água perto de ar condicionados ou equipamentos calorificos e locais com temperaturas excessivamente quentes ou frias.
Seite 35: Joining The Front And Rear Cabinets
Joining the Front and Rear Cabinets Remove 4off Button head screws (M8x35) and remove the Joint Brackets from inside the Gun Cabinet. (Do not lose the screws as these are required for refitting later). Button head screw (M8x35) x2 Button head screw (M8x35) x2 Spring washer (M8) x2...
Seite 36 Connect the connectors and slide the Gun Cabinet upto the Target Cabinet, taking care not to trap any wires, and retain using the 4off Button head screws removed in 1 above. Joint bracket Threaded Hole Connectors Target Cabinet Connectors Button head screw (M8x35) x2 each side Spring washer...
Seite 37: Removing The Flat Target Packing
Removing the Flat Target Packing. Remove the four off Button head screws (M5x35) and remove the rear upper door on the Target Cabinet. (Note: Take care that the door does not fall when removing the four screws ). Button head screw Target cabinet (M5x35) Rear maintenance door (U)
Seite 38: Adjustments
6. ADJUSTMENTS Adjustment or maintenance on this machine should be carried out by qualified personnel only. Einstellungen und Wartung des Gerätes dürfen nur von dafür qualifiziertem Fachpersonal vorgenommen werden. Justeringer eller vedligehold af denne maskine bør kun udføres af kvalificeret personale. Los ajustes y el mantenimiento de esta máquina deben ser realizados sólo por personal cualificado.
Seite 39: Adjustment Switches
Adjustment Switches The Adjustment switches are located inside the coin door. Service Switch. Press this switch to obtain game credits without incrementing the play meter, to change the settings when in the Setting Mode and to select test numbers when in the Test Mode.
Seite 40: Setting Mode
Setting Mode This mode allows the changing of various game and price settings. 6-2-1 Setting Mode Operation Slide the Test switch on while pushing the Select switch. The item and settings are displayed on the Dot Matrix Display. The selected item changes each time the Select switch is operated.
Seite 41: Ticket Payout Setting
6-2-2 Ticket Payout Setting Do not operate in ticket mode without a ticket dispenser connected 1. Free ticket setting This setting when ON will pay one ticket at the end of each game if no score tickets have been awarded. 2.
Seite 42: Test Mode
Test Mode Open the coin door and slide the test switch “ON”. The Test Item and Test No. (number) are displayed on the Dot Matrix Display. Press the Select switch to step to the next Item. Press the Service switch to change the Test No. (number). Each time the service switch is pressed the Test No.
Seite 43: Adjusting The Launcher Solenoid
Adjusting the Launcher Solenoid The Launcher Solenoid must be adjusted after replacement. Loosen the 4off socket flange head screws (M6x10), only sufficiently so that the solenoid bracket can just be moved by hand. If the screws are loosened too much it will make it difficult to adjust the solenoid. Lower the solenoid bracket in the direction of arrow (a), and hold it in place by hand so that it does not move up.
Seite 44: Adjusting The Shutter Solenoid
Adjusting the Shutter Solenoid The Shutter Solenoid must be adjusted after replacement. Loosen the 4off socket flange head screws (M5x8), only sufficiently so that the solenoid can just be moved by hand. If the screws are loosened too much it will make it difficult to adjust the solenoid. Cup target cover Adjust so that the space between the shutter solenoid...
Seite 45: Adjusting The Flat Target (U)/(L) Solenoids
Adjusting the Flat Target (U)/(L) Solenoids The Flat Target (U)/(L) Solenoid must be adjusted after replacement. Loosen the 4off socket flange head screws (M5x8), only sufficiently so that the solenoid can just be moved by hand. If the screws are loosened too much it will make it difficult to adjust the solenoid. Move and hold the solenoid plunger in the direction of arrow (a).
Seite 46: Maintenance
7. MAINTENANCE Adjustment or maintenance on this machine should be carried out by qualified personnel only. Ensure that the POWER to the machine is turned OFF before commencing any maintenance work. (Trouble shooting, service or repairs etc.) Einstellungen und Wartung des Gerätes dürfen nur von dafür qualifiziertem Fachpersonal vorgenommen werden.
Seite 47 Aanpassingen of onderhoud aan deze machine dient alleen uitgevoerd te worden door bekwaam personeel. Zorg ervoor dat de machine UITgeschakeld is voordat er enig onderhoudswerk wordt verricht (troubleshooting, reparaties etc.) Afinações ou manutenção nesta maquina, deverão ser efectuadas sómente por pessoal qualificado. Certifique-se que a maquina se encontra desligada sempre que iniciar qualquer tipo de trabalho de manutenção.
Seite 48: Regular Cleaning
Regular Cleaning This game relies upon light to operate correctly and it is important that glasses, mirrors, sensors and lenses are kept clean. Never use any solvent products to clean the above items as the solvent may cause irreparable damage. 7-1-1 Cleaning the Glasses and Half Mirror.
Seite 49: Cleaning The Cup Target Sensor
7-1-3 Cleaning the Cup Target Sensor Never use any solvent products to clean the sensor as the solvent may cause irreparably damage. Remove the display cover as described in section 7-9 page 62. Remove the maintenance door as described in section 7-10 page 64 Move the Cup Target Cover in the direction of the arrow, in the following figure, and clean the surface of the sensor with a clean cotton swab.
Seite 50: Cleaning The Gun Lens
7-1-4 Cleaning the Gun Lens Never use any solvent products to clean the lens as the solvent may cause irreperable damage. Wipe and clean the surface of the Gun Lens with a clean, dry, lint free cloth. Soft, dry cloth Lens Gun Assy Page 50...
Seite 51: Cleaning The Fibre Optic Cable
7-1-5 Cleaning the Fibre Optic Cable Never use any solvent products to clean the Fibre Optic Cable as the solvent may cause irreparable damage. Remove the Fibre Optic Cable as described in section 7-30 page 93 Wipe and clean the surface of the Fibre Optic Lens with a clean, dry, lint free cloth.
Seite 52: Cleaning The Gun Holster Detection Sensor
7-1-6 Cleaning the Gun Holster Detection Sensor Never use any solvent products to clean the lens as the solvent may cause irreparable damage. Remove the holster cover as described in section 7-26 page 87. Wipe and clean the surface of the Gun Holster Detection Sensor with a clean, dry, lint free cloth.
Seite 53: Replacing The Game Pc Board
Replacing the Game PC Board Note: The Game PC Board is susceptible to damage from static electricity. Anti static precautions should be taken when removing, handling and refitting the Game PC Board. Remove the 2off Button head screws (M5x35) and remove the rear maintenance door (L) of the Target Cabinet.
Seite 54: Replacing The Cup Target Sensor Pc Board
Replacing the Cup Target Sensor PC Board Remove the upper rear maintenance door from the Target Cabinet. Remove the connectors. Using needle nosed pliers, squeeze the locking tabs of the locking supports, one at a time, to release the PC Board. Remove the Sensor PC Board. Replace the board by gently pushing the board on to the locking supports.
Seite 55: Replacing The Rear Glass
Replacing the Rear Glass Remove the upper rear maintenance door from the Target Cabinet. Remove 4off pozi flange head screws (M5x12) and remove the Chip Slope (L). Remove 4off pozi flange head screws (M5x12) and remove the Chip Slope (R). Remove the 4off Button head screws (M5x35) and remove the window plates.
Seite 56: Replacing The Light Guard
Replacing the Light Guard Remove the Upper Rear Door from the Target Cabinet. Remove 3off Pozi head screws (M4x16) and remove the light Guard in the direction of the arrow in the diagram below Light Guard Pozi head Screw (M4x16) Rear Glass Note: The Rear Glass is located below the Light Guard.
Seite 57: Replacing The Rear Fluorescent Tubes And Starters
Replacing the Rear Fluorescent Tubes and Starters. Remove the Light Guard. (see section 7-5 page 56). Replace the Fluorescent Lamp or Starter. Note: The fluorescent lamp has an effect on the appearance of the game field, so replace only with 20 watt coolwhite fluorescent. 20watt Coolwhite Fluorescent Tube Starter...
Seite 58: Replacing The Front Acrylic
Replacing the Front Acrylic Remove 6off security screw (M5x12) and remove the Header Front Cover. Security screw (M5x12) Security screw (M5x12) Security screw (M5x12) Disconnect the two connectors: CN11 and CN12. Remove 4off Pozi head screws (M5x25) and pull the Header Panel forward a little to unfasten it from the hooks, and disconnect the connectors: CN45 and CN46.
Seite 59 Remove the 4off Security screws (M5x12) and remove the Front Acrylic Retaining brackets. Note: The Front Acrylic will tilt forward when the retaining brackets are moved, so ensure that the acrylic is being held in place with a hand. Retaining bracket Security screw (M5x12) Front Acrylic...
Seite 60: Replacing The Half Mirror
Replacing the Half Mirror Remove the Front Acrylic. (see section 7-7 page 58). Remove the 4off Button head screws (M5x16) and remove the upper Half Mirror Retaining brackets (left and right). Half Mirror Button head screw (M5x16) Retaining bracket (upper) Button head screw (M5x16) Retaining bracket...
Seite 61 Hold the mirror both top and bottom and remove it in the direction of the arrow, as shown in the diagram below. Indicator label Target Cabinet Half mirror Refit the Half Mirror in the reverse order. Note: There is a small label in the upper left corner of the mirror to indicate the front surface of the mirror.
Seite 62: Replacing The 7-Segment Pc Board
Replacing the 7-Segment PC Board Note: The 7-Segment PC Board is susceptible to damage from static electricity. Anti static precautions should be taken when removing, handling and refitting the 7-Segment PC Board. Remove 4off security screw (M5x30) and remove the Display Cover. Display Cover Security screw (M5x30)
Seite 63 Remove 6off pozi head screws (M4x12) that retain the 7-Segment Pc Board. 7-Segment PC Board Display bracket Pozi head screw (M4x12) Disconnect the connector and remove the 7-Segment Display PC Board. Display bracket Connector 7-Segment PC Board Refit in the reverse order. Page 63...
Seite 64: Replacing The Front Fluorescent And Starter
7-10 Replacing the Front Fluorescent and Starter Remove the Display Cover. (See section 7-9 page 62) Remove 2off Security screws (M5x35) that retain the front maintenance door. Pull the front maintenance door forward in the direction of the arrow, as shown in the diagram below, only sufficiently to disconnect the connectors.
Seite 65 Only loosen 2off Pozi flange head screws (M4x8) and remove the Cover B. Pozi flange screw (M4x8) Cover B Shutter Assy Replace the Fluorescent Tube or Starter. Fluorescent Tube 20watt Coolwhite Reassemble in reverse order. Note: The fluorescent lamp has an effect on the appearance of the game field, so replace only with 20 watt coolwhite fluorescent.
Seite 66: Replacing The Cup Target Sensor Assy
7-11 Replacing the Cup Target Sensor Assy Remove the upper rear maintenance door from the Target Cabinet. Remove the Display Cover and Front Maintenance Door. (see section 7-10 page 64). Disconnect connector J301 from the Sensor PC Board and free the harness from the front of the Target Cabinet.
Seite 67 Remove 3off Pozi head head screws (M4x12) and remove the Cup Target Sensor from the mounting bracket. Pozi head screw Cup Target (M4x12) Cup Target Sensor Assy Connector J301 Cup Target Sensor Bracket Pozi head screw (M4x45) (with flat and spring washers) Replace the sensor Assy and reassemble in reverse order.
Seite 68: Replacing The Header Fluorescent And Starter
7-12 Replacing the Header Fluorescent and Starter. Remove the Header Front Cover. (see section 7-7 page 58) Fluorescent Tube (15watt) Starter Lamp Lamp 24v / 15w 24v / 15w Replace the Fluorescent Tube or Starter. Reassemble in reverse order. Page 68...
Seite 69: Replacing The Header Lamp
7-13 Replacing the Header Lamp Remove the Header Front Cover. (see section 7-7 page 58) Remove the Header Lamp by unscrewing the lamp in the direction of the arrow, shown in the diagram below. Replace the lamp and reassemble in reverse order. Lamp 24v / 15w Page 69...
Seite 70: Replacing The Dot Matrix Display
7-14 Replacing the Dot Matrix Display. Remove the Header Front Cover. (see section 7-7 page 58) Remove 2off pozi head screws (M4x12) and remove the Dot Matrix Cover. Pozi head screw (M4x12) Dot Matrix Cover Remove the 4off pozi head screw (M5x25), 1off lock washer and ring tag terminal and gently pull the display bracket forward taking care not to strain any wires.
Seite 71 Disconnect the connectors (CN45 and CN46), remove 4off pozi head screw (M4x12) and remove the Dot Matrix Display from the Display Bracket. Connector Connector (CN45) (CN46) Pozi head Screw (M4x12) Display Bracket Dot Matrix Assy Reassemble in the reverse order. Page 71...
Seite 72: Replacing The Launcher Solenoid
7-15 Replacing the Launcher Solenoid Remove the upper rear maintenance door from the Target Cabinet. Remove 1off pozi flange head screw (M4x6) and disconnect the Ring Tag Terminal and Connector (CN25). Remove 4off socket flange screws (M6x10), with flat and spring washers, and remove the Launcher Solenoid.
Seite 73: Replacing The Launcher Sensor
7-16 Replacing the Launcher Sensor Remove the upper rear maintenance door from the Target Cabinet. Disconnect the connector (CN26). Remove 2off pozi flange head screws (M4x6) and remove the Launch Sensor complete with Sensor Bracket. Connector (CN26) Sensor Bracket Pozi flange screw (M4x6) Remove 1off pozi head screw (M4x12) and remove the Launch Sensor from the Sensor Bracket.
Seite 74: Replacing The Shutter Solenoid
7-17 Replacing the Shutter Solenoid Remove the Front Maintenance Door from the Target Cabinet (See section 7-10 page 64). Disconnect connector (CN28). Remove 4off socket flange screws (M5x8) and remove the Shutter Solenoid. Socket Flange Screw (M5x8) Ring Tag Connector (CN28) Shutter Solenoid Spacer...
Seite 75 To remove the solenoid plunger remove one of the E-Clips from the solenoid shaft#2, the flat washer (M6) and spacer (6dia x 5). Withdraw the solenoid shaft#2 releasing the solenoid springs, tension spring, spacers (6dia x 10), and delrin washers. Delrin Washer Install the solenoid spring (S) so the spring hook comes in contact with...
Seite 76: Replacing The Shutter Sensor
7-17 Replacing the Shutter Sensor Remove the Front Maintenance Door from the Target Cabinet (See section 7-10 page 64). Disconnect connector (CN30). Tilt the Cup Target Cover in the direction of arrow (a), shown in the diagram below. Remove 2off flange socket head screws (M5x8) and remove the stopper bracket in the direction of arrow (b), shown in the diagram below.
Seite 77: Removing The Flat Target Assembly
7-18 Removing the Flat Target Assembly Remove the upper rear door from the Target Cabinet. Disconnect the connectors (CN20) and (CN22), remove 2off pozi flange head screws (M4x6) to release the harnesses. Connector (CN22) Harness Connector (CN21) Connectors (CN20) Harness Connector (CN29) Pozi flange screws...
Seite 78: Replacing The Flat Target Solenoid
7-19 Replacing the Flat Target Solenoid Remove the Flat Target Assy. (See section 7-18 page 77) Remove the pozi flange head screw (M4x6) to release the nylon clip retaining the harness coming from connector (CN20). Flange Socket Screws (M5x8) Pozi Flange Screw Solenoid Plunger (M4x6) Cable Clip...
Seite 79 To remove the solenoid plunger, remove one of the E-Clips and flat washer (M6). Withdraw the Solenoid Shaft releasing the spacers and spring. Solenoid Shaft E-Clip Flat Washer (M6) Arm Shaft Spacer Solenoid Spring Spring Spacer Flat Washer (M6) E-Clip Flat Target Solenoid Solenoid Plunger...
Seite 80: Replacing The Flat Target Drive Cable
7-20 Replacing the Flat Target Drive Cable Remove the upper rear maintenance door from the Target Cabinet. Remove 2off flange socket screws (M4x6) and remove the Flat Target Drive Cable. Flange Socket Screw (M4x6) Wire Bracket Flat Target Drive Cable Reassemble in reverse order.
Seite 81: Replacing The Flat Target Motor
7-21 Replacing the Flat Target Motor Remove the upper rear maintenance door from the Target Cabinet. Remove the Flat Target Drive Cable (See section 7-20 page 80). Disconnect connectors (CN21) and (CN24). Loosen 2off double point screws (M5x6) and remove the pulley in the direction of the arrow, as shown in the diagram below.
Seite 82 Replace the motor and reassemble in reverse order. Note: The shaft of the flat target motor has been ground flat in two places. When replacing the pulley ensure that the two double point screws are in contact with these flat faces. Flat Target Flat Section Motor Shaft...
Seite 83: Replacing The Flat Target Sensor Pc Board
7-22 Replacing the Flat Target Sensor PC Board Note: PC Boards are susceptible to damage from static electricity. Anti static precautions should be taken when removing, handling and refitting the PC Board. Remove the Flat Target Assembly. (See Section 7-18 page 77). Disconnect connectors (J301) and (J302).
Seite 84: Replacing The Flat Target Position Detection Sensor
7-23 Replacing the Flat Target Position Detection Sensor Remove the upper rear maintenance door from the Target Cabinet. Disconnect connector (CN48) Remove 1off pozi head screw (M4x12) and remove the Flat Target Position Detection Sensor Connector (CN48) Flat Target Positition Detection Sensor Flat Target Solenoid...
Seite 85: Replacing The Flat Target Sensor Assy
7-24 Replacing the Flat Target Sensor Assy Remove the Flat Target Assembly. (See Section 7-18 page 77). Remove 2off pozi head screws (M4x6) and remove the Target Plate. Pozi flange screw (M4x6) Target Plate Flat Target Sensor Assy Disconnect the connector (CN50). Remove 2off flange socket screw (M4x12), 1off flange socket screw (M4x10) and remove the Flat Target Sensor Assy.
Seite 86: Replacing The Flat Target Origin Sensor
7-25 Replacing the Flat Target Origin Sensor Remove the upper rear maintenance door from the Target Cabinet. Disconnect connector (CN24). Remove 1off pozi head screw (M4x12) with flat washer (M4) and remove the Flat Target Detection Sensor. Flat Target Origin Detection Sensor Connector (CN24)
Seite 87: Replacing The Gun Detection Sensor
7-26 Replacing the Gun Detection Sensor Remove 1off security screw (M5x20), 1off security screw (M5x10) and remove the Holder Cover. Holder Cover Security Screw (M5x20) Security Screw (M5x10) Holder Bracket (R) Gun Detection Sensor (projection side) Holder Bracket (L) Instruction Panel Gun Detection Sensor Holder Bracket (C)
Seite 88 Disconnect the connector (CN39). Remove the pozi head screw (M3x12) and remove the Gun Detection Sensor (projection side). Holder Bracket (L) Pozi Head Screw (M3x12) Gun Detection Sensor (projection side) Gun Cabinet Front Holder Bracket (R) Connector (CN39) Reassemble in reverse order. Note : Repeat above procedures to remove the Gun Detection Sensor (receiving side).
Seite 89: Replacing The [Set] And [Start] Lamps
7-27 Replacing the [SET] and [START] Lamps Remove 6off security screws (M4x25), with flat washers, and remove the Set / Start Acrylic. Security Screw (M5x25) Washer (M4) Set / Start Acrylic Gun Cabinet Remove the lamp by turning it in the direction of the arrow, shown in the diagram below.
Seite 90: Replacing The Speaker
7-28 Replacing the Speaker Remove 5off Security screws (M5x20) and remove the Top Cover. Security screw (M5x20) Top Cover Gun Cabinet Remove 4off pozi head screws (M5x25), with flat and spring washers, and lift the Speaker Box in the direction of the arrow, as shown in the diagram below. Pozi head screw (M5x25) Speaker Box...
Seite 91 Remove the 4off Self Tapping screws (No8 x ” ) and remove the Speaker Cover. Speaker Cover Self tapping screw (N08 x ") Speaker Box Gun Cabinet Remove the 4off , Self Tapping screws (No8 x ” ) disconnect the Faston terminals and remove the Speaker.
Seite 92: Replacing The Holder Cushions (A) (B) (C)
7-29 Replacing the Holder Cushions (A) (B) (C) Remove the Holder Cover and Holder Bracket (C). (See section 7-26 page 87) The Holder Cushions (A) (B) (C) are attached using double-sided adhesive tape. Pull firmly on the cushion and peel it from the holder bracket. Holder Cushion (A) Holder Bracket (C) Holder Cushion (B)
Seite 93: Replacing The Xenon Pc Board
7-30 Replacing the Xenon PC Board CAUTION The Xenon Assy remains hot and continues to carry a high voltage charge even after turning the power OFF. Wait at least five minutes after turning the power OFF before performing any maintenance work (troubleshooting, repairs etc.) on the Xenon Assy. Note: PC Boards are susceptible to damage from static electricity.
Seite 94 Disconnect connector (CN41) and the Fibre Optic in the direction of the arrow, as shown in the diagram below. Fibre Optic Xenon PC Board Connector (CN41) Using needle nosed pliers, squeeze the locking tabs of the locking supports, one at a time, to release the PC Board. Remove the Xenon PC Board. Locking Supports Xenon PC Board Locking Supports...
Seite 95 Reassemble in reverse order. Note: In order to ensure the correct light output from the gun Assy, the fibre optic should be fitted as close as possible to the Xenon Tube. When installing the fibre optic, be careful not to touch the Xenon tube with your fingers or hands.
Seite 96: Replacing The Xenon Drive Pc Board
7-31 Replacing the Xenon Drive PC Board CAUTION The Xenon Assy remains hot and continues to carry a high voltage charge even after turning the power OFF. Wait at least five minutes after turning the power OFF before performing any maintenance work (troubleshooting, repairs etc.) on the Xenon Assy. Note: PC Boards are susceptible to damage from static electricity.
Seite 97: Removing The Xenon Fan And Filter
7-32 Removing the Xenon Fan and Filter CAUTION The Xenon Assy remains hot and continues to carry a high voltage charge even after turning the power OFF. Wait at least five minutes after turning the power OFF before performing any maintenance work (troubleshooting, repairs etc.) on the Xenon Assy. Remove 2off pozi head screws (M4x12) and remove the Filter Bracket.
Seite 98: Replacing The Gun Assy
7-33 Replacing the Gun Assy Note: When removing the Gun Assy from the top cover on the Gun Cabinet, take care not to bend, pull or scratch the harness or fibre optic cable. Remove the Fibre Optic Cable. (See section 7-30 page 93) Remove 4off Security screw (M5x10) that retains the Pipe Bracket, and pull the Gun Assy out from the Gun Cabinet.
Seite 99: Replacing The Gun Switch, Trigger And Lens
7-34 Replacing the Gun Switch, Trigger and Lens Loosen 2off screws (M3x8) retaining the Gun Sight. Remove 7off cap bolts (M3x8) and remove Gun Side (R). The grip is permanently fixed to the gun side (R). Sight Gun Side (R) Pozi head screws (M3x8) Cap Bolts...
Seite 100 Replace the Gun Switch, Trigger or Lens and reassemble in reverse order. Note: If the Fibre Optic Holder has come off, reattach it by aligning the marking on the Fibre Optic Holder with the marking on the Gun Side (L). Install the Lens so that the convex (curved) surface is facing outward.
Seite 101: Replacing The Gun Harness Assy
7-35 Replacing the Gun Harness Assy Remove the Fibre Optic Cable. (See section 7-30 page 93) Remove 2off cap bolts (M3x6) and remove the Harness Guide from the Pipe Bracket. Remove 1off Pozi head screw (M5x20), Hex nut (M5) and unfasten the Pipe Clip and Pipe Bracket.
Seite 102 Remove the Gun Side (R) and Grip (R). (See section 7-34 page 99). Disconnect the 2off Fast-on terminals from the Gun Switch. After removing the Gun Switch and Trigger, remove 1off self tapping screw (M3x8) and remove the Gun Bracket. Gun Harness Assy Fibre Optic Self Tapping Screw...
Seite 103 Reassemble in reverse order. Note: The tie wraps on the Gun Harness Assembly should be installed so that they come in contact with the gun bracket, as shown in the diagram below. Tie Wrap Gun Bracket Note: Install the Fibre Optic Holder by aligning the marking on the holder with the marking on the gun side (L).
Seite 104: Error Messages
8. ERROR MESSAGES This game is constantly monitoring its operation. If an error is detected, a message is displayed on the Dot Matrix Display, an error code is displayed on the 7 Segment Display and an audible warning sounded. For errors in the table below, the message “Please Call Attendant”...
