Hardware Explanations
1 Plug the adapter into the DC-IN port.
The power LED will light up when your hardware is ready.
2
XD4R Overview
LAN port
DC-IN port
WAN/LAN port
Connect your modem to this port with a network cable.
LAN port
Connect your PC to a LAN port with a network cable.
Specifications:
DC Power adapter
Operating Temperature
Operating Humidity
WAN/LAN port
DC Output: +12V with max 1.5A current
0~40 o C
50~90%
XD4N Overview
DC-IN port
+12V with max 2A current
Storage 0~70
Storage 20~90%
LAN port
o C
3
