6. Attach the seat
1)
Hold the seat (14) above the frame (08). Locate the seat
connector posts (15) into the seat attachment slots (16) on the
frame (08). Ensure that the seat (14) "click" into place. Pull up
to confirm seat (14) is assembled securely.
2)
Push forward the seat (14) as picture.
3)
Engage the backrest recline button (17) on backrest (18) while
reclining the backrest (18) to proper position.
4)
Then lift up the bumper bar (23).
NOTE: There are three recline positions of backrest (18).
5)
The seat (14) can be fitted forward or rearward facing
6)
To remove the seat (14): Press seat release buttons (19) on both
sides while lifting seat (14) off frame (08).
GB
06
07
14
16
07
08
08
09
14
09
.
10
11
10
11
7. Rear brake
15
WARNING: Always apply BOTH BREAKES whenever the stroller
08
is stationary. Never leave your child unattended. Never leave
the stroller on a sloped surface with a child in seat, even with
the brakes applied.
1)
Push down the brake pedal (09) near the rear wheel (03) to set
the brake.
2)
Lift up pedal (09) to release the brake.
8. To use safety harness
1)
Press the button of the buckle to release the belt.
2)
Insert the tongues of the buckle to install the belt.
23
17
9. Storage basket
18
WARNING: Do not load the storage basket (10) with weights
over 2.5 KG.
14
1)
The stroller is equipped with a storage basket (10).
10. Front Swivel Wheel
1)
To lock swivels: push down fixed direction lock (11).
To unlock swivels: lift up fixed direction lock (11).
2)
14
08
19
12
13
14
15
16
17
18
12
13
09
03
14
15
16
10
17
11
18
11
GB
