Instructions for sharpening and honing
1. Mounting the Accessory
Remove the knife jig from the
machine and replace it with the
RBS-140 Round Blade Sharp-
ening Attachment (hereafter
referred to as the "Accessory").
2. Setting the blade size
Measure the outer diameter
of the blade. The Accessory is
compatible with blades of sizes
80–140 mm in diameter.
Remove the supplied stop ring
and attach it to the machine's
shaft against the Accessory to
hold it in place.
To set the size, loosen the
guide's stop screw and slide it
to the desired size. Tighten the
stop screw again to lock.
140 mm
(5½")
120 mm
(423/32")
100 mm
(315/16")
80 mm
(3")
The markings on the shaft refer
to blade diameter, as illustrated
above. Note that the dimen-
sions are approximate.
