Operating instructions
Quartz clock movement with 2 hands
Item no. 2521755
Intended use
The clock movement is used to display the time.
To this end, a dial is installed and provided with suitable hands.
The watch may only be operated by a battery (for the type, refer to "Technical data").
The product may only be used in enclosed indoor locations; outdoor use is not permitted. Do not expose to
moisture, under any circumstances.
For safety and approval reasons, you may not convert and/or alter the product in any way. If you use the
product for other purposes than those described above, the product may be damaged. Furthermore, im-
proper use may cause risks such as short-circuits, fire, injuries, etc. Please read the operating instructions
carefully and do not discard them. Please include these operating instructions when you pass the product
on to a third party.
This product complies with the applicable national and European Regulations. All names of companies and
products are the trademarks of the respective owners. All rights reserved.
Package contents
• Quartz clock movement
• 2 sets of hands
• Operating instructions
Up-to-date operating instructions
Download the latest product information at
the instructions on the website.
Explanation of symbols
The symbol with the exclamation mark in the triangle is used to indicate important information in
these operating instructions. Always read this information carefully.
The arrow symbol indicates special information and advice on operation.
Safety instructions
Please read the operating instructions carefully and pay particular attention to the safety
instructions. We do not assume liability for any injuries/material damages resulting from
failure to observe the safety instructions and the information in these operating instruc-
tions regarding the proper use of the product. Furthermore, in such cases, the warranty/
guarantee will be null and void.
a) General information
• Please handle the product with care. It can be damaged by impact, blows, or by being
dropped, even from a low height.
• Do not expose the product to high temperatures, dampness, moisture, strong vibrations or
heavy mechanical loads.
• This product is not a toy and should be kept out of reach of children. Only use the product
out of the reach of children. The product contains small parts and a battery that could be
swallowed.
• Do not leave the packaging material lying around carelessly, since it could become a danger-
ous toy for children.
• If safe operation is no longer possible, take the device out of service and secure it against
unintended use. Safe operation is no longer possible, if the product:
- shows visible damage,
- no longer functions properly,
- has been stored under adverse ambient conditions for an extended period of time or
- has been exposed to considerable strain during transport.
• Maintenance, adjustment and repair work should only be carried out by an expert or a spe-
cialised workshop.
• If you have any questions that are not answered in these operating instructions, please con-
tact our technical customer service or another specialist.
b) Battery Instructions
• Batteries should be kept out of the reach of children.
• Do not leave batteries lying around in the open; there is a risk of them being swallowed by
children or domestic animals. If swallowed, consult a doctor immediately.
• Leaking or damaged batteries can cause burns if they come into contact with the skin. You
should therefore wear suitable protective gloves.
• Batteries must not be short-circuited, opened or thrown into a fire. There is a danger of explo-
sion!
• Do not recharge normal, non-rechargeable batteries; they may explode! Only recharge re-
chargeable batteries that are intended for this purpose; use a suitable battery charger.
• Please pay attention to the correct polarity (plus/+ and minus/-) when inserting the battery.
www.conrad.com/downloads
or scan the QR code shown. Follow
Montage
• Loosen the central hex nut of the hand shaft, and remove it along with the washer. The rubber disc remains
on the clock movement.
• Attach the clock movement from the back through the borehole of the clock-face and align it horizontally.
• Place the washer above the hand shaft, and tighten the clock movement with the middle hexagon nut. In
this process, make sure you don't tighten the nut too firmly to avoid twisting and damages.
• First, carefully attach the hour hand to the hand shaft, then the minute hand and lastly the second hand.
• Align all the hands of the clock to the 12 o'clock position.
• Make sure the hands are aligned parallel to the clock-face so that they don't touch each other during
operation or rub against the clock-face.
Inserting the battery
• Insert a battery of type 1.5 V Mignon/AA into the battery compartment on the back of the casing, while
observing the correct polarity. The correct polarity is indicated inside the battery compartment.
• Replace the battery once the clock stops or the accuracy of the clock movement decreases.
Setting the time
Set the time by turning the white dial on the rear of the housing. The adjustment knob can be rotated in both
directions here.
Maintenance and cleaning
Do not use abrasive cleaning agents, cleaning alcohol or other chemical solutions since these
could damage the housing or even impair operation.
You can use a clean, dry, soft cloth for cleaning. Dust can be easily removed with a soft, clean brush.
Disposal
a) Product
This symbol must appear on any electrical and electronic equipment placed on the EU market.
This symbol indicates that this device should not be disposed of as unsorted municipal waste
at the end of its service life.
Owners of WEEE (Waste from Electrical and Electronic Equipment) shall dispose of it separate-
ly from unsorted municipal waste. Spent batteries and accumulators, which are not enclosed by
the WEEE, as well as lamps that can be removed from the WEEE in a non-destructive manner,
must be removed by end users from the WEEE in a non-destructive manner before it is handed
over to a collection point.
Distributors of electrical and electronic equipment are legally obliged to provide free take-back of waste.
Conrad provides the following return options free of charge (more details on our website):
• in our Conrad offices
• at the Conrad collection points
• at the collection points of public waste management authorities or the collection points set up by manufac-
turers or distributors within the meaning of the ElektroG
End users are responsible for deleting personal data from the WEEE to be disposed of.
It should be noted that different obligations about the return or recycling of WEEE may apply in countries
outside of Germany.
b) (Rechargeable) batteries
Remove batteries/rechargeable batteries, if any, and dispose of them separately from the product. According
to the Battery Directive, end users are legally obliged to return all spent batteries/rechargeable batteries; they
must
not
be
disposed
Batteries/rechargeable batteries containing hazardous substances are labelled with this symbol
to indicate that disposal in household waste is forbidden. The abbreviations for heavy metals in
batteries are: Cd = Cadmium, Hg = Mercury, Pb = Lead (name on (rechargeable) batteries, e.g.
below the trash icon on the left).
Used (rechargeable) batteries can be returned to collection points in your municipality, our stores or wher-
ever (rechargeable) batteries are sold. You thus fulfil your statutory obligations and contribute to environ-
mental protection.
Batteries/rechargeable batteries that are disposed of should be protected against short circuit and their
exposed terminals should be covered completely with insulating tape before disposal. Even empty batteries/
rechargeable batteries can contain residual energy that may cause them to swell, burst, catch fire or explode
in the event of a short circuit.
Technical data
Battery .................................................. 1 x 1.5 V Mignon battery (AA)
Battery life ............................................. approx. 10 months
Accuracy ............................................... max. 30s/month (@ 1.5 V and 25 °C)
Clock face thickness ............................. max. 2.5 mm
Mounting hole ....................................... 8 mm
Length of hand shaft ............................. 6 mm
Hand hole ............................................. 5.5/3.7 mm (hour/minute hands)
Dimensions ........................................... 56 x 56 x 17 mm
Weight .................................................. 99 g
Operating temperature range ............... -10 to +50 °C
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights in-
cluding translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represents the technical status at the time of printing.
Copyright 2022 by Conrad Electronic SE.
of
in
the
normal
household
*2521755_V1_1022_02_dm_mh_en
waste.
