Technical information

Application:
For the geometric smoke removal and natural ventilation of:
• Light domes
• Aluminium dark flaps
• Continuous rooflight flaps
Product features:
• With overload unit for "CLOSE" direction and travel-dependent
switch-off in "OPEN" direction
• For solo, tandem and group operation
• Potential-free contact for "OPEN" display
Contact rating: max. 230VAC/2A
Nominal voltage:
Current consumption:
Stroke lenght:
Stroke speed:
Pushing force:
Tensile force:
Closure force:
Protection rating:
Operating temperature:
Switch-on duration:
Housing:
Housing colour:
Housing extension:
Housing dimensions: LxWxD
Weight:
Connection cable:
Cable cross-section:

Technical data:

24VDC ± 10%
approx. 500mm
approx. 6mm/s
-15°C to +50°C
30% (3 min per 10 min)
RAL-9010
RAL-9016
680 x 75 x 114mm
approx. 2.5kg
approx. 1.5 metres
5 x 0.75mm²
1A
500N
150N
3000N
IP54
Plastic
