Franke SIRIUS Installations- Und Gebrauchsanweisung

Sirius Pull Out Nozzle Chrome | 115.0476.760
FAMILY : Taps | SERIE : Sirius | FINISH : Chrome | INSTALLATION TYPE : Worktop/Sink | INSTALLATION TYPE : WORKTOP |
MODEL : Pull Out Nozzle
TECHNICAL DATA
Version
Tap rotation
Diameter
Height Overall
Tap Operation
Tap Hole
Spout reach
Cartridge
Position of lever
Tap Pressure
Height to End of Spout
Base
Flexy Tails
Max worktop height
Type of Material
Installation Option
Global Marketing | | | 2021-08-05
PULL-OUT-NOZZLE
360 °
Ø-35-MM
344.00 mm
Side Lever
35
210.00 mm
Ø-35-MM
RIGHT
High Pressure
310.00 mm
Ø-50
M10*1*3/8*400 length, stainless steel
40.00 mm
BRASS
shank M38*1.25-M33*1.5-φ35*55
FEATURES
Single
lever
Lockwasher
Tap hole
35 mm
