2,5" mounting 1
2,5" mounting 1
3,5" mounting
Screws D
Screws E
Connectors
LED Lightning
Connector LED
Front panel
A
C
B
D
Switch
E
Input
Molex 12V=
A - E additional connectors for fans
©2018 Inter-Tech Elektronik Handels GmbH - Hainhäuser Weg 93 - 30855 Langenhagen - Germany
vertrieb@inter-tech.de - www.inter-tech.de
- Remove both side panels.
- Hold the hard disks at the inner side.
- Remove right side panel.
- Hold the hard disks at the outer side.
- Mount screws D onto the hard disks.
- The RGB controller is completely connected on delivery.
- You can place the controller somewhere in the case by yourself due to the adhesive tape at the back of the controller.
- Follow the figure on left side when re-connecting the cables of the controller.
- Connect the power cable of the controler directly to a Molex connector of the power supply.
- Connectors A to E can be used for additional RGB fans, which will be controlled by the switch. Please use only fans espacially made for that case.
- Fix it from outside with screws B.
- Fix it from above and from below with Screws
B.
- Remove right side panel.
- Insert hard disk into the bracket. Keep
connectors outside.
- Fix the hard disk with screws E.
