English Operation (see page 5) Safety Notes Hansgrohe recommends not to use as drinking water Gloves should be worn during installation to prevent the first half liter of water drawn in the morning or after crushing and cutting injuries. a prolonged period of non-use. The product may only be used for bathing, hygienic and body cleaning purposes. The hot and cold supplies must be of equal pressures. Installation Instructions • Prior to installation, inspect the product for transport damages. After it has been installed, no transport or surface damage will be honoured. • The pipes and the fixture must be installed, flushed and tested as per the applicable standards. • The plumbing codes applicable in the respective countries must be observed. Technical Data Operating pressure: max. 1 MPa Recommended operating pressure: 0,1 - 0,5 MPa Test pressure: 1,6 MPa (1 MPa = 10 bar = 147 PSI) Hot water temperature: max. 60°C Thermal disinfection: 70°C / 4 min The product is exclusively designed for drinking water! Symbol description Do not use silicone containing acetic acid! Adjustment (see page 6) To adjust the hot water limiter. Using a hot water limiter...
Deutsch Reinigung (siehe Seite 5) Sicherheitshinweise Bedienung (siehe Seite 5) Bei der Montage müssen zur Vermeidung von Quetsch- und Schnittverletzungen Handschuhe Hansgrohe empfiehlt, morgens oder nach längeren getragen werden. Stagnationszeiten den ersten halben Liter nicht als Das Produkt darf nur zu Bade-, Hygiene- und Trinkwasser zu verwenden. Körperreinigungszwecken eingesetzt werden. Große Druckunterschiede zwischen den Kalt- und Warmwasseranschlüssen müssen ausgeglichen werden. Montagehinweise • Vor der Montage muss das Produkt auf Transport- schäden untersucht werden. Nach dem Einbau werden keine Transport- oder Oberflächenschäden anerkannt. • Die Leitungen und die Armatur müssen nach den gültigen Normen montiert, gespült und geprüft werden. • Die in den Ländern jeweils gültigen Installationsricht- linien sind einzuhalten. Technische Daten Betriebsdruck: max. 1 MPa Empfohlener Betriebsdruck: 0,1 - 0,5 MPa Prüfdruck: 1,6 MPa (1 MPa = 10 bar = 147 PSI) Heißwassertemperatur: max. 60°C Thermische Desinfektion: 70°C / 4 min Das Produkt ist ausschließlich für Trinkwasser konzipiert!
Seite 4
98996000 SW 11 mm (7 Nm) SW 23 mm SW 9 mm (4 Nm)
Seite 5
SW 22 mm SW 22 mm (2 Nm) > 2 min www.hansgrohe.com/ www.hansgrohe.com/ cleaning-recommendation cleaning-recommendation open / öffnen close / schließen cold / kalt hot / warm www.hansgrohe.com/ www.hansgrohe.com/ www.hansgrohe.com/ cleaning-recommendation cleaning-recommendation cleaning-recommendation www.hansgrohe.com/ www.hansgrohe.com/ www.hansgrohe.com/ www.hansgrohe.com/ cleaning-recommendation cleaning-recommendation cleaning-recommendation cleaning-recommendation Cleaning recommendation / Warranty / Contact Reinigungsempfehlung / Garantie / Kontakt...
Seite 6
60 °C 10 °C 0,3 MPa 36°C 38°C 50°C 60°C 43°C 55°C 17 x...
