1
> Intercom Cleaner Socket
2
> Intercom Console (1)
< Intercom Power Supply
< Intercom Connection Hub (1)
> Intercom Power Supply
> Intercom Connection Hub (1)
1a
2a
< Intercom Cleaner Socket
< Intercom Console (1)
> Intercom Connection Hub (6)
1b
(DC Power)
< Intercom Power Supply
15V
/700mA
1a
2
1
Wandsteckdose
Wandsteckdose
100-240V
100-240V
~
~
50-60Hz
50-60Hz
8
> Intercom RJ45 Connector (1)
3
< Intercom Microphone
> Intercom R45 Connector (2)
3a
< Intercom Connection Hub (2)
> Intercom Connection Hub (2)
3b
< Intercom R45 Connector (2)
Kontroll-Raum
Sprechanlage
mit Fußschalter
2m
2m
1b
5
2a
3b
4a
3m
4
> Intercom Speaker
> Intercom Connection Hub (4)
5
< Intercom Connection Hub (3)
< Footswitch (4)
4a
> Intercom Connection Hub (3)
< Intercom Speaker
Montage Lautsprecher
Patienten-Raum
1m
3
Deckenmontage Mikrofon
20m
5
3a
20m
H
C
C
Wichtig für die Installationsplanung:
Dimensionen Mikrofonkabel:
Länge 1m, Ø 2,6mm
Verlängerungskabel Länge 20m, Ø 5,5mm
Durchgangsloch für RJ45-Kupplung
mindestens Ø38mm
Bohrbild beachten!
Dimensionen Lautsprecherkabel:
Länge 20m, Ø 5,5mm
Durchgangsloch für RJ45-Stecker
mindestens Ø17mm.
N
Dimensionen Montage Material
4
siehe Seite 4.
3 8
J
Bohrbild
6 5
9
