TP302 TP326 Forest Growable Swing IN1902-C 01 16.qxp_TP302 TP326 Forest Growable Swing IN1902-C 01 16 13/01/2016 12:25 Page 8
Stage
Low Height - ssembly
4
PM1007 x1
22 Degree
Angled Foot
PM2019
x4
Angled Foot PM2019
SSEMBLY TIP
Only attached Angled feet/Stakes if building for Low Height usage.
For Full Height ssembly - Do not fit ngled feet/Stakes just yet.
Go to stage 7
Ground peg x4
PM2001
M6 x 80mm
x4
FA5168
M6 Washer
M6 x 80mm
Bolt
8
M6 Nylon Insert
M6 x 20mm
Dome Nut
Washer
FA5192
FA5094
x4
x4
SSEMBLY TIP
Fit for both low and full height assembly
M8 x 30mm
Coach screw
M8 x 30mm
Coach screw
SSEMBLY TIP
Drill 3mm
Pilot Holes
M6
Washer
M6 Nylon
Insert Nut
M8 x 30mm
Coach screw
FA5124
x4
M8 x 25mm
Large washer
FA7184
x4
Forest Acorn Growable Swing Frame
