Introduction

We would start by thanking you for having chosen our product and hope that you will be happy with your choise.
In order that your STONEBURIER Mod. TST will serve you well for many years, we ask you to pay attention to
the instructions for use and maintenance which you will find in this manual. Observance of these regulations will
prevent breakdowns and accidents for which our R2 company will not accept responsability.
This use and maintenance manual is to be considered an integral part of the machine itself and therefore it must
always accompany the machine when it is sold, even in the event of its sale to third parties.
If you keep this manual in a safe place and in good condition, you - and whoever must use the machine - will be
able to have a complete, legible reference on hand at all time.

Prevention of accidents

Most accidents that occur during work, maintenance or the moving of a machine are due to negligence in the
observance of the most elementary rules of accident prevention.
It is, therefore, necessary that all qualified user, (relatives, employees, colleagues) scrupulously read and note the
rules written below and on the adhesive stickers on the machine itself.
1. Turn off the engine-driven cultivator before making any adjustments, carryng out maintenance or clearing.
Before any adjustments it is necessary to place the machine on the floor or on firm stands.
2. The STONEBURIER Mod. TST has been manufactured for a specialized use. It must, therefore, always be
in perfect working condition and anly R2 spare parts should be used when making repairs.
3. It is most omportant that the tightness of the nuts and screws are checked before use, especially those of
the hoes.
4. Before starting up, make sure that no people or animals are in the vicinity.
5. Take special care when working alongside roads or pathways.
6. Do not leave the tractor running without supervision.
7. During checking or repairing, make sure that nobody can start up the machine accidentally.
8. Close fitting garments should be worn in order to avoid getting caught in moving parts.
9. Do not carry loads or people on the machine or tractor during work or on the road.
10. During work, the safety guards on the cardan shaft must always be in place and fastened with the security
chains that prevent rotation.
11. Do not, for any reason, climb into the machine during operation.
12. Do not interfere with any object on the machine during operation.
13. Never use the machine without the back roller, graded and sides, since these provide protection to the
machine.
14. When adjusting the grader, always turn off the tractor and carry out such adjustaments in conditions of
absolute safety.
Contruction features
The STONEBURIER Mod. TST is the only machine that can be applied to low-powered tractors, levels mills and
compresses the earth in a single operation.
As can be seen from the illustration (fig.1), the STONEBURIER Mod. TST is equipped with an adjustable-height
scraper on the front to shift the earth (fig.1 - ref.A), a central rotating harrow to crumble the earth (fig.1 - ref.B),
and a special grilled roller at the back (fig.1 - ref.C), which makes it possible to adjust the working depth of the
rotating harrow and to compress the earth.
The STONEBURIER Mod. TST is especially suitable in preparing the soil for fields, gardens, sporting facilities,
vegetable gardens and anyone who needs the ground to be perfectly levelled
