REMOTE OPERATING POLE
FOR SPOTLIGHTS · LS OP 1
SAFETY INFORMATION
1. Please read these instructions carefully before you start installation
and assembly.
2. Keep all information and instructions in a safe place.
3. Follow the instructions.
4. Observe all safety warnings. Never remove safety warnings or other
information from the equipment.
5. Be attentive when setting up the product and protect yourself from injury.
6. This product is intended for indoor use only. Using it outdoors could lead to
product failure and personal injury.
7. Do not modify this equipment.
8. Comply with all applicable disposal laws in your country. During disposal
of packaging, please separate plastic and paper/cardboard.
9. Plastic bags must be kept out of reach of children.
10. If you have any questions refering to this instruction or any warnings,
please contact your local distributor.
MANUFACTURER'S WARRANTY & LIMITATION OF LIABILITY
You can find our current warranty conditions and limitation of liability at:
https://cdn-shop.adamhall.com/media/pdf/MANUFACTURERS-DECLARA-
TIONS_GRAVITY.pdf
To request warranty service for a product, please contact Adam Hall GmbH,
Adam-Hall-Str. 1, 61267 Neu Anspach / Email Info@adamhall.com /
49 (0) 6081 / 94 19-0
PROPER DISPOSAL OF THIS PRODUCT
(WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT)
(Valid in the European Union and other European countries with waste
separation)
This symbol on the product, or the documents accompanying the product,
indicates that this appliance may not be treated as household waste. This is
to avoid environmental damage or personal injury due to uncontrolled waste
disposal. Please dispose of this product separately from other waste and
have it recycled to promote sustainable economic activity.
Gravity is a registered brand of the Adam Hall Group
®
FEATURES
• Simple and effective alignment of spotlights at great heights
• Length: 200-640 cm (adjustable via three extensions)
• Integrated hook for aligning the spotlight
• Crank (removable) for rotation of the hook
• Robust and lightweight aluminium construction
DESCRIPTION
Anyone who works as a lighting technician in theatres, TV studios, congress
centres or other production venues knows: the optimal illumination of a
stage is precision work. At the same time, the tight schedules of a produc-
tion rarely allow for fetching a ladder every time to manually adjust static
spotlights high up in the rig - not to mention the safety risk for the people
on site.
With the LS OP 1, Gravity has a solution for these situations in its portfolio.
The extendable operating pole enables the alignment of installed spot-
lights at great heights. The adjustment options include the pan and tilt
angle, as well as focus adjustment (Pan/Tilt/Focus) via standard bells and
the folding of barndoors.
The maximum length of 6.4 m is achieved via three individually lockable
extensions and can be extended to the desired length in a few simple
steps. In addition, the robust but lightweight aluminium construction facil-
itates operation enormously.
At the upper end of the LS OP 1 is the integrated hook for hanging in the
pan/tilt/focus bells. The crank at the lower end of the pole allows the hook
to be easily turned into the desired position. The crank can be removed for
easy and space-saving transport.
SPECIFICATIONS
Product number
Product type
Type
Poles material
Poles color
Poles diameter
Extension max.
Extension min.
Number of extensions
Sleeves material
Crank material
Handle material
Bar handle material
Hook material
Transport length
Interchangeable rings
Black ring pack included
Weight
Adam Hall GmbH | Adam-Hall-Str. 1
61267 Neu-Anspach | Germany
GLSOP1
Other Lighting Accessories
Operating pole
Aluminum
Black
28.24.20.16 mm
6400 mm
2000 mm
3
Rubber
Steel
Plastic
Plastic
Steel
2000 mm
1x 25 mm
Yes
2.02 kg
