HIKVISION DS-KV9503-WBE1 Bedienungsanleitung

DS-KV9503-WBE1
Video Intercom Villa Door Sta�on
UDB
Diagram References
1 Appearance
1 Microphone 2 Camera 3 Indicator 4 Bu�on 5 Card Reading Area
6 Loudspeaker 7 Terminals 8 Debugging Port 9 TAMPER
10 Set Screw 11 TF Card Slot 12 Network Interface
Note: The debugging port is used for debugging only.
Indicator Descrip�on
Unlock: Green Call: Orange Communicate: White
2 Terminal and Wiring
NC: Door Lock Relay Output (NC) AUO: Audio Input
NO: Door Lock Relay Output (NO)
485-: RS-485 Interface
COM: Common Interface 485+: RS-485 Interface
AIN1&AIN2: For the access of Door Contact 12 VDC IN: Power Supply Input
AIN3&AIN4: For the access of Exit Bu�on
GND: Grounding
3 Installa�on Accessory
1 Moun�ng Template 2 Moun�ng Plate
Note: The dimension of the moun�ng plate is 102.58 mm × 39.24 mm × 6.2 mm.
4 Installa�on
Note: Video intercom villa door sta�on supports surface moun�ng.
Before You Start
Make sure all related equipments are power-off during the installa�on.
Tools that you need to prepare for installa�on:
Drill (ø2.846) and gradienter.
Purchase the protec�ve shield before installa�on.
Surface Moun�ng without Protec�ve Shield
1. S�ck the moun�ng template on the wall. Drill screw holes according to the moun�ng
template. Remove the template from the wall.
2. Secure the moun�ng plate on the wall with 4 supplied screws according to the screw
holes.
3. Install the villa door sta�on to the moun�ng plate. Fix the device on the moun�ng
plate with the set screw.
Surface Moun�ng with Protec�ve Shield
1. S�ck the moun�ng template on the wall. Drill the screw holes according to the
moun�ng template. Remove the template from the wall.
2. Align the protec�ve shield with the moun�ng template.
3. Secure the moun�ng plate and protec�ve shield on the wall with 4 supplied screws
according to the screw holes.
4. Install the villa door sta�on to the moun�ng plate. Fix the device on the moun�ng
plate with the set screw.
5 Configura�on via Web
1 Ac�vate Device via Web
You are required to ac�vate the device first by se�ngs a strong password before you
can use the device.
Default parameters of door sta�on are as follows:
Default IP Address: 192.0.0.65.
Default Port No.:8000.
Default User Name: admin
1. Power on the device, and connect the device to the network.
2. Enter the IP address into the address bar of the web browser, and click Enter to enter
the ac�va�on page.
Note: The computer and the device should belongs to the same subnet.
3. Create and enter a password into the password field.
4. Confirm the password.
5. Click OK to ac�vate the device.
Note: When the device is not ac�vated, the basic opera�on and remote configura�on of device cannot be
performed.
2 Access to the Device by Web Browsers
1. In the browser address bar, enter the IP address of the device, and press the Enter
key to enter the login page.
2. Enter the user name and password and click Login.
3 Communicate with Indoor Sta�on
1. Click Se�ngs -> Intercom -> Press Bu�on to Call to enter the se�ngs page.
2. Set the parameters.
- Edit call No. for every bu�on.
- Check Call Management Center to set the bu�on calling center.
Note: If you check Call Management Center and set the call No. as well, call management center has
higher privilege than call No.
3. Press bu�on to call indoor sta�on.
4 Issue Card
1. Click Se�ngs -> Access Control and Elevator Control to enter the se�ngs page.
2. Click Issue Card. Present the card on the card reading area.
3. When issuing finished, the windows pop up on the se�ngs page.
Note:
Only Mifare card supported, and Mifare card with non-standard shape is recommended.
Up to 10000 cards can be issued and managed by V series door sta�on. A voice prompt (No more cards
can be issued.) can be heard when the issued card amount exceeds the upper limit.
5 Unlock Door
A�er issuing cards, you can unlock the door by presen�ng the issued cards.
Refers to Video Intercom Villa Door Sta�on User Manual (scan the QR code) for details.
1 1
3
1 1
Hole Hole
1
2
102023104
The recommended distance from the ground level is 1.40
adjustable depends on the height of body.
1 1
Hole Hole
2
Hole
4
Surface Moun�ng without Protec�ve Shield
Villa Door Station 2
3
Screws Mounting Plate
Surface Moun�ng with Protec�ve Shield
Villa Door Station
Screws
3
4
Screws Mounting Plate
39.24
3.45
1.18
Unit : mm
6.2
1
Mounting Template Wall
1
2
Protective Shield Mounting Template Wall
2
4
Recommended Installation Height (The distance between the camera and the ground): 1.4 m to 1.6 m
Horizontal: 129°
1.4 m
0.5 m
Highest Height: 1.88 m
Vertical: 75°
Lowest Height: 1.12 m
1.5 m
0.5 m
Yellow/Purple AUO
Black GND
Yellow/Red AI1
Yellow/White AI2
Yellow/Blue AI3
Yellow/Green AI4
Black GND
White/Blue NC1
White/Green COM1
White/Red NO1
White/Purple NC2
White/Grey COM2
White/Brown NO2
Yellow 485+
Blue 485-
Black GND
Red 12VDC
Black GND
Highest Height: 1.78 m
Vertical: 75°
Lowest Height: 1.02 m
0.5 m
Highest Height: 1.98 m
Vertical: 75°
Lowest Height: 1.22 m
1.6 m
0.5 m
