Chauvet DJ Intimidator Beam 360X Kurzanleitung Seite 4

EN
Menu Map
Refer to the Intimidator Beam 360X product page on
Main Level
Address
DMX
Slave
RF
Run Mode
Manual
Pan Reverse
Tilt Reverse
Screen Reverse
Pan Angle
Setup Totem Mode
Sensitivity
DMX Loss
Flash if DMX
3
QUICK REFERENCE GUIDE
Programming Levels
001–512
14CH
8CH
Slave1–4
Auto
Sound
RF 1–4
RFP
Pan
Tilt
Color
Gobo
Prism 000–255
Focus
Frost
Dimmer
Shutter
OFF
ON
OFF
ON
OFF
ON
540
360
180
270
Tilt Angle 180
OFF
UP
DOWN
001–100
Hold
Black
Auto
Sound
ON
Indicator
OFF
ON
OFF
RF Bind
Reset
Factory Set
www.chauvetdj.com
Description
Sets the DMX starting address
Selects DMX mode
Selects Slave mode 1, 2, 3, or 4
Selects Auto mode
Selects Sound-Active mode
Sets the product to work with the RFC-XL remote in group 1, 2, 3,
or 4. (RF remote must be bound to the product first)
Sets the product to work with public RF signal
Manual pan control
Manual tilt control
Manual color control
Manual gobo control
Manual prism control
Manual focus control
Manual frost control
Manual dimmer control
Manual shutter control
Normal pan operation
Reverse pan operation
Normal tilt operation
Reverse tilt operation
Normal display
Reverse display
Selects the 540° pan angle range
Selects the 360° pan angle range
Selects the 180° pan angle range
Selects the 270° tilt angle range
Selects the 180° tilt angle range
90 Selects the 90° tilt angle range
Does not restrict the pan and tilt motion
Restricts the pan and tilt motion for overhead mounting
Restricts the pan and tilt motion for surface/floor mounting
Sets sound sensitivity
Holds the last setting when signal is lost
Blacks out the product when signal is lost
Sets the unit to Auto mode when signal is lost
Sets the unit to Sound mode when signal is lost
Enables/disables LED Indicator
Sets whether the LED indicator flashes when the fixture is
connected to or disconnected from the DMX
Shows instructions on how to bind the RF remote to the product
Resets the product
Loads factory defaults
for the latest menu map.
Intimidator Beam 360X QRG Rev. 1
