PS 4.5 PLUS
5.

TecHNIcAL SPecIFIcATIONS

5.1

Portable tube saw PS

TYPe OF MAcHINe
Dimensions (l x b x h)
Machine weight
(without accessories and case)
Power
Protection class
Speed
Versions
Vibration level in accordance with
EN 28662, part 1
Sound pressure level at workplace
* The sound pressure level was measured under normal operating conditions in accordance with EN 50144-1. As the noise level in unfavorable operating conditions can
also rise above 80 dB (A), it is necessary to wear ear protection in accordance with DIN EN 352.
5.2

Line laser

Dimensions (lxw)
Power, total emitted
Power for classification
Beam range
Wave length
Operating voltage
Operating current
Operating temperature
Storage temperature
Laser class
Battery type
[REV. 20200320] OC_PS_BA_790048761_00__INH-02_EN
PS 4.5 PLUS
[mm] 480 x 230 x 600
[inch] 20.9 x 9.1 x 23.6
[kg] 23.6
[lbs] 52.0
[W] 1100
[hp] 1.5
[class] Totally insulated in accordance with class II, DIN VDE 0740
[rpm] 30 – 165
[V, Hz] 110 V, 50/60 Hz
120 V, 50/60 Hz
230 V, 50/60 Hz
[m/s²] < 2.5
[dB (A)] approx. 78
*)
[mm] 68 x 15
[inch] 2.7 x 0.59
[mW] 5
[HP] 5x10-6
[μW] < 390
[m] 1
[inch] 3.937
[nm] 650
[V DC] 2.8 to 4.5
[mA] 20
[°C] -10 to 40
[°C] -40 to 80
[class] 1
2 x LR44 / AG13
Technical specifications
