ANSCHLÜSSE (ABB.1)
MIC/LINE IN
Balanced male XLR
LINK (output)
Balanced female XLR
TOP OUTPUTS (speaker outputs)
Speakon Cable Connector
2-WIRE CABLE (optional)
STEREO & DUAL modes
LEFT TOP & RIGHT TOP outputs
n.c.
2+
2-
n.c.
2 hot
cold
3
ground
1
INGRESSO MIC/LINE
XLR bilanciato maschio
ground
1
3 cold
2
hot
LINK (uscita)
XLR bilanciato femmina
TOP negative
1-
1-
1+
TOP positive
1+
MIC/LINE IN
Jack (balanced)
MIC/LINE IN
Jack (unbalanced)
*Note: connect both cold and ground
to make cable from balanced to
unbalanced.
TOP OUTPUTS (uscite altoparlanti)
Connettore per cavo tipo Speakon
4-WIRE CABLE (supplied)
MONO & DOUBLE modes
LEFT TOP output only
TOP B positive 2+
2+
2-
TOP B negative 2-
1 tip - hot
2 ring - cold
sleeve - ground
3
INGRESSO MIC/LINE
Jack (bilanciato)
tip - hot
1
cold
2
ground
3
INGRESSO MIC/LINE
Jack (sbilanciato)
*Nota: connettere insieme cold e
ground per cavi da bilanciato
a sbilanciato.
1- TOP A negative
1-
1+
1+ TOP A positive
