DeLOCK 87765 Bedienungsanleitung

Declaration of conformity
Products with a CE symbol fulfill the EMC directive (2014/30/EU), the
ErP directive (2009/125/EC), LVD directive (2014/35/EU) and RoHS directive
(2011/65/EU+2015/863), which were released by the EU-comission.
The declaration of conformity can be downloaded here:
http://www.delock.de/service/conformity
WEEE-notice
The WEEE (Waste Electrical and Electronic Equipment)-directive, which became
effective as European law on February 13th 2003, resulted in an all out change
in the disposal of disused electro devices. The primarily purpose of this directive
is the avoidance of electrical waste (WEEE) and at the same time the support of
recycling and other forms of recycling in order to reduce waste. The WEEE-logo on
the device and the package indicates that the device should not be disposed in the
normal household garbage. You are responsible for taking the disused electrical
and electronical devices to a respective collecting point. A separated collection and
reasonable recycling of your electrical waste helps handling the natural resources
more economical. Furthermore recycling of electrical waste is a contribution to
keep the environment and thus also the health of men. Further information about
disposal of electrical and electronical waste, recycling and the collection points
are available in local organizations, waste management enterprises, in specialized
trade and the producer of the device.
EU Import: Tragant Handels- und Beteiligungs GmbH
Beeskowdamm 13/15, 14167 Berlin, Germany
Support Delock
If you have further questions, please contact our customer support
support@delock.de
You can find current product information on our homepage: www.delock.com
Final clause
Information and data contained in this manual are subject to change without notice
in advance. Errors and misprints excepted.
Copyright
No part of this user's manual may be reproduced, or transmitted for any purpose,
regardless in which way or by which means, electronically or mechanically, without
explicit written approval of Delock.
Edition: 07/2020
User manual
Mode d'emploi
Uživatelská příručka
Manuale utente
Manual de utilizare
Korisnički priručnik
4 Port Gigabit Ethernet Switch PoE +
SFP
English
Description
This Gigabit Ethernet Switch by Delock can be used to connect different network
components. The four RJ45 ports support Power over Ethernet according to
IEEE802.3af / 802.3at, so they can supply power to PoE-enabled devices, such as
an IP camera or a PoE splitter via the network cable.
The additional SFP slot allows to expand the network with a fiber optic connection.
Specification
• Connectors:
4 x RJ45 jack PoE
1 x SFP slot for 1 Gbps SFP module
1 x DC 5.5 x 2.1 mm female
• Output power: max. 30 W per port, max. 60 W total
• Data transfer rate up to 1 Gbps
• LED indicator for link and activity
• Supports IEEE 802.3at PoE+
• Phantom power (Mode A, pairs 1/2 and 3/6)
• Metal housing
• Fanless
• Dimensions (LxWxH): ca. 153 x 87 x 29 mm
Power supply specification
• Power supply with IEC connector
• Input: AC 100 ~ 240 V / 50 ~ 60 Hz / 1.5 A
• Output: DC 48.0 V / 3.74 A
• Ground outside, plus inside
• Dimensions:
inside: ø ca. 2.1 mm
outside: ø ca. 5.5 mm
length: ca. 9 mm
Bedienungsanleitung
Manual del usuario
Instrukcja obsługi
Bruksanvisning
Használati utasítás
Εγχειρίδιο χρήστη
Product-No:87765
User manual no:87765-a
