DeLOCK 80164 Bedienungsanleitung

Declaration of conformity
Products with a CE symbol fulfill the EMC directive (2014/30/EU) and
RoHS directive (2011/65/EU+2015/863+2017/2102), which were released by the
EU-comission.
The declaration of conformity can be downloaded under documents:
https://www.delock.de/produkte/G_80164/merkmale.html
WEEE-notice
The WEEE (Waste Electrical and Electronic Equipment)-directive, which became
effective as European law on February 13th 2003, resulted in an all out change
in the disposal of disused electro devices. The primarily purpose of this directive
is the avoidance of electrical waste (WEEE) and at the same time the support of
recycling and other forms of recycling in order to reduce waste. The WEEE-logo
on the device and the package indicates that the device should not be disposed
in the normal household garbage. You are responsible for taking the disused
electrical and electronical devices to a respective collecting point. A separated
collection and reasonable recycling of your electrical waste helps handling the
natural resources more economical. Furthermore recycling of electrical waste is
a contribution to keep the environment and thus also the health of men. Further
information about disposal of electrical and electronical waste, recycling and
the collection points are available in local organizations, waste management
enterprises, in specialized trade and the producer of the device.
Cet appareil
se recycle
Points de collecte sur www.quefairedemesdechets.fr
EU Import: Tragant Handels- und Beteiligungs GmbH
Beeskowdamm 13/15, 14167 Berlin, Germany
Support Delock
If you have further questions, please contact our customer support
support@delock.de
You can find current product information on our homepage: www.delock.com
Final clause
Information and data contained in this manual are subject to change without notice
in advance. Errors and misprints excepted.
Copyright
No part of this user's manual may be reproduced, or transmitted for any purpose,
regardless in which way or by which means, electronically or mechanically, without
explicit written approval of Delock.
Edition: 06/2025
User manual
Mode d'emploi
Uživatelská příručka
Manuale utente
Manual de utilizare
Korisnički priručnik
Industrial Gigabit Ethernet Switch
4 Port PoE 1 Port RJ45 1 Port SFP for
DIN rail
English
Description
This robust, industry capable Gigabit Ethernet switch by Delock can be used to
connect different network components. The four RJ45 ports support Power over
Ethernet according to IEEE802.3af / 802.3at, so they can supply power to PoE-
enabled devices, such as an IP camera or a PoE splitter via the network cable.
The additional SFP slot allows to expand the network with a fiber optic connection.
Redundant power supply with 48 V to 57 V
The switch accepts two terminal power sources, allowing it to be permanently
connected to multiple power sources, enabling applications that require high
availability.
Technical details
• Connectors:
4 x RJ45 jack for 10/100/1000 Mbps Base-T (PoE+)
1 x RJ45 jack for 10/100/1000 Mbps Base-T
1 x SFP slot for 1 Gbps SFP module
1 x 5 pin terminal power connector
• Data transfer rate up to 1 Gbps
• Supports IEEE 802.3 / 802.3u / 802.3z / 802.3ab
• Supports IEEE 802.3af PoE
• Supports IEEE 802.3at PoE+
• Industrial standards: IEC 61000-4-2 (ESD), IEC 61000-4-4 (EFT), IEC 61000-4-5
(Surge) level 4
• Industrial standards: IEC 60068-2-6 (Vibration), IEC 60068-2-27 (Shock), IEC
60068-2-32 (Free fall)
• Output power: 30 W per port
• VLAN port Isolation
• LEDs for status monitoring
• Redundant power supply with 48 V to 57 V
• Robust metal housing
• Fanless
• Suitable for 35 mm DIN rail
• Protection class: IP40
• Operating temperature: -40 °C ~ 85 °C
• Dimensions (LxWxH): ca. 116 x 85 x 33 mm
Bedienungsanleitung
Manual del usuario
Instrukcja obsługi
Bruksanvisning
Használati utasítás
Εγχειρίδιο χρήστη
Product-No: 80164
User manual no: 80164-a
www.delock.com
