EN
2. To pry out the 4pcs trunk-nails from the left side of the
cabinet, and then fix them to the right side.( as picture
FIG.C, FIG.D and FIG.E )
14
FIG.C
Trunk-nail
FIG.D
FIG.E
Trunk-nail
3. To rotate the door 180 degrees, and to align the upper
and lower hinges with the hinge holes of the left side.
To adjust the door, and tighten the screws with hexagon
wrench, and then complete the door replacement. (as
picture FIG.F, FIG.G and FIG.H)
FIG. F
FIG. G
FIG. H
