ELLIPSE WIRELESS CAR CHARGER
USER MANUAL
Epico Ellipse Wireless Car Charger is a magnetic phone holder to be fitted to a ventilation grille
and a wireless charger in one device. Thanks to the strong magnet, it reliably holds the phone
throughout the ride. The charger charges your iPhone with the latest series with an output power
of 7.5W and other smartphones with an output of up to 15W.

Product specifications

Ellipse Wireless Car Charger
Output power: 15W & 10W & 7.5W
Input current/voltage: 5V/2.4A, 9V/2A
Output current/voltage: 5V/1A, 5V/1.5A, 9V/1.2A, 9V/1.67A
Input interface: USB-C
Material: aluminum alloy, plastic
Dimensions: 65x100x8mm
Weight: 90g
USB-C PD MINI CAR CHARGER
Input: 12-24V/1.8A
Output: 12-24V/1.8A (50-60Hz)
Maximum power: 18W
Material: ABS + PC
Dimensions: 43x24mm
Weight: 12g
USB-C Cable
Type: USB-C to USB-C
Material: PVC
Length: 1m
Weight: 20g

Package contents

1x Ellipse Wireless Car Charger
1x USB-C PD MINI CAR CHARGER
1x USB-C cable
1x Ventilation grile holder
1x Manual
Operating instructions
1. Screw the ventilation grille holder to the charging base using the thread on the rear side
of the charger.
2. Attach the magnetic charger to the air conditioning ventilation grille.
3. Use the USB-C cable to connect the charger to the USB-C socket in your car.
4. You can recognize charging thanks to the LED indicator, which lights up blue for the
entire charging time.
5. Take your phone and bring it close to the front of the charger, which automatically grips it
thanks to a strong magnet.

Safety instructions

Before using the car charger, be sure to carefully read the safety instructions below.
1. If your phone falls down due to improper attachment during your drive, park your car in
a suitable place and fix the phone securely and properly in the device
2. Under all circumstances, pay maximum attention to your drive. Handling of the charger
must not jeopardize driving safety in any case.
3. Do not install the charger near an air-bag. A released air-bag might throw the charger and
cause an injury of a car passenger.
4. Before your drive, check the attachment of the charger so that it should not get released
during the drive or the phone should not fall out.
Operating conditions and maintenance
1. Do not use the charger near magnets.
2. Only use the specific cables and power supply unit for the power supply.
3. Do not expose the device to extremely high or extremely low temperatures. The operating
temperature of the device is -10 to +55°C. Do not leave the charger in your car in summer.
4. Do not expose the charger to moisture. Possible moisture may cause short-circuiting of the
electric wiring and damage the device.
5. Before cleaning the device, disconnect the charger from the electric mains.
6. Do not use detergents, alcohol or other cleaners to clean the device. Use a clean and dry cloth.
7. Do not throw the product and do not expose it to impacts or other physical harm.
8. Do not disassemble the product or adapt it in any way; you might damage it and lose the
manufacturer's warranty.
9. Do not leave the device near chips and chip cards, cardiac pacemakers and other
magnetic devices.
10. If the product does not work, please, contact the manufacturer.
Disclaimer
This wireless car charger is only intended to be used in combination with a suitable mobile
device. Before the first use of the charger and new device verify their mutual compatibility.
The manufacturer is not liable for possible damages of a mobile device or other equipment
caused by improper use of this product in any respect.
This symbol on the product or in the accompanying documentation indicates
that the product must not be considered a regular municipal waste and must
be disposed of in accordance with local regulations. Pass thi product for
environmentally safe disposal. Proper disposal of this product protects the
environment. For more information, contact your local municipal waste disposal
office, the nearest collection point or your dealer.
This product complies with all the essential requirements of the EU directives that
apply to it.
EN
