Power Supply; Product Overview; Controls; Status Indicators - Heraeus Soluva air T Bedienungsanleitung

without chemicals and produces no harmful
byproducts such as ozone.
The UV lamp inside this device destroys the
structure of the genetic material in microor-
ganisms using highly disinfecting UV-C light
with a wavelength of 254 nanometers. This
prevents their ability to replicate.
The built-in fan circulates the air in the
room pulling the air through the UV lamp for
disinfection.
Soluva Air T can disinfect the air in small
®
rooms up to a maximum of 16 m² and a
ceiling height of a maximum of 2.50 m such
as offices, meeting rooms, treatment rooms,
hospital rooms and living rooms.
For optimal disinfection place the device on
a table in the immediate vicinity of people.
If two or more people are sitting at a table,
the device should be placed in the middle of
the table if possible. (Fig. 7)

4. Power Supply

Company Name,
address, city, country
Model Identification
Line Voltage
Line Frequency
Output Voltage
Output Current
Output Power
Mean Efficiency
MW
No.28, Wuquan 3rd
Road, Wugu Dist., New
Taipei City 24891,
Taiwan.
GSM60A24-P1J
80 – 264 V AC
47 – 63 Hz
24 V DC
2.5 A
60.0 W
90.88 %
Low Efficiency (10%)
Standby Power

5. Product Overview

Fig. 1.
A: Cover with air outlet grille
B: Air intake slot
C: Control panel
D: 24 V connector
E: Power cord
F: 24 V Device connector
G: Power supply
H: Slot for opening the lid

6. Controls

Fig. 2.
A: Control panel on/off switch
B: Timer control
C: Selectable operating times
D: Status display
E: Selectable fan speeds
F: Fan speed control

7. Status Indicators

Fig. 3.
A: The device is in standby mode.
B: The device is in the warm-up phase after
switching on.
C: The device is in normal operation.
D: The end of life of the UV-C lamp is
approaching.
E: The end of life has been reached.
Q: There is a malfunction.
G: The device has completely switched off
for safety.
≈ 84 %
≈ 0.075 %
23
