CODMV1250/1600/2000A3P
CODMV(S)…
I
2
Mounting dimensions
e
f
b
c
a
DMV160N
DMVS160N, DMVS250N, DMVS400N
DMV630N, DMV1000N
DMV1250N, DMV1600N, DMV2000N/3P
4/4
EU: Eaton Industries GmbH, Hein-Moeller-Straße 7-11, 53115 Bonn, Germany
UK: Eaton Electrical Products Ltd, Melton Road, Burton-on-the-Wolds, Leicestershire, LE12 5TH, United Kingdom
4 mm
2 Nm
(17.7 lb-in)
K6...VERL
DMV160A
DMVS160A
DMV250A
DMV400A
DMV630A
DMV1000A
g g
h h
a
b
290 mm (11.42")
130 mm (5.12")
376 mm (14.8")
170 mm (6.69")
534 mm (21.02")
240 mm (9.45")
660 mm (25.98")
170 mm (6.69")
M 5
1 Nm
(8.85 lb-in)
4K14K6H...
l1
70 mm (2.76")
70 mm (2.76")
70 mm (2.76")
70 mm (2.76")
151 mm (5.94")
168 mm (6.61")
≤ 630 A
h = Shaft-specific
c
d
30 mm (1.18")
90 mm (3.54")
36 mm (1.42")
110 mm (4.33")
54 mm (2.13")
145 mm (5.71")
220 mm (8.66")
225 mm (8.86")
Eaton.com/contacts
Eaton.com/aftersales
Eaton.com/documentation
l
200 mm (7.87")
200 mm (7.87")
200 mm (7.87")
200 mm (7.87")
328 mm (12.91")
355 mm (13.98")
1000 A
e
f
g
6 mm (0.24")
–
95 mm (3.74")
7 mm (0.28")
–
103 mm (4.06")
7 mm (0.28")
–
143 mm (5.63")
9 mm (0.35")
390 mm (15.35")
153 mm (6.02")
© 2016 Eaton Industries GmbH
Eaton.com/recycling
07/21 IL008039ZU
