Operation Power Supply
Cleaning cycle
During the cleaning cycle, the cleaner: moves across the pool floor picking up dirt and
debris. Changes direction and rotates automatically according to the selected program.
Climbs the pool walls every few minutes, as set in its internal program. Note: The robotic
cleaner might occasionally stop moving for a few seconds. This is part of normal
operation, not a malfunction.
Stopping robotic cleaner operation
The robotic cleaner moves automatically to 'standby' after every cleaning cycle and the
on/off button starts flashing. To stop the cleaner operation during a cleaning cycle, press
the operation button once. On/off button starts flashing and the cleaner is in standby
mode.
On/Off
Pulling cleaner unit out of the water
(1) Unplug the floating cable from the power supply. (2) Pull the floating cable until the
unit is close enough to reach the handle. (3) Using the handle, lift the cleaner out of the
pool. CAUTION: Do not use the floating cable to lift the cleaner out of the water.
The power supply is connected to the robotic
cleaner via the floating cable (1). The unit is
powered by AC power (2) and supplies low voltage
2
and commands to the robotic cleaner through the
outlet socket.
The power supplies feature a control panel with
indicators:
a. On/Off (all models)
22
IMPERIAL ROBOTIC POOL CLEANER
