EN
INSTRUCTION

5.8 Adjust the Length of Support Leg

Pull out the support leg to the maximum angle.
a)Press the adjust button of support leg, hold the
support leg using the other hand and then
adjust the length of support leg.
b)When support leg is in full contact with the
ground of vehicle so that can release the adjust
button. Pull the support leg to make sure it is locked.
NOTE: c)After finishing the installation of support
leg, display window turns into green color.
15
17

5.9 Removing Sleeping Pad

When your child's height exceed 61cm, remove
the sleeping pad.
3
2 1
picture 1
40-105cm

5.10 Removing and Putting on the Fabric Cover

1. Remove the 5-point harness.
2. Take off the cover from the backrest and base.
3. Move the headrest of the child seat up to the
highrest position.
4. First take the cover off base of the
headrest, then remove the cover of the
headrest.
To re-fit the cover, Firstly put on the headrest's cover,
then put on the plastic shell's cover in the order of
①②③ ( see picture1)
Never use the child seat without having
it correctly installed
Check that the harness straps are not
twisted and that they have been correctly
inserted in the belt slots of the cover.
16
18
