INSTRUCTION
5.4 Adjust safety belt length
A Tighten Safety Belt
Pull up shoulder belt and the lap belt will
tighten, then pull crotch belt to tighten safety
belt.
Tighten the safety belt as much as possible without
causing discomfort to the child. The lap belt is as
low as possible and should put near child's crotch
not abdomen.
P.S.: Loose safety belt is dangerous. Please
check safety belt adjuster whether work, then
tighten safety belt. After tightening the seat belt,
adjust the shoulder pads to the appropriate position
on the chest.
B Loosen Safety Belt
When press the safety belt adjuster, the other hand
must grasp the safety belt which under shoulder
pads and pull it forward to release the safety belt.
9
A:
B:

5.5 Adjust the Rotation of the Seat

Pull the rotation adjuster out with your thumb,
then rotate the safety seat to 360 degree angle.
( see picture a )
ACTION: Each time rebound the rotation adjuster
back. To make sure the seat is fixed well.
A. Rearward Direction: (40-105cm),
must use rearward direction ( see picture 1)
B. Forward Direction: ( 76-105cm ),
must use forward direction ( see picture 2)
C. When the seat is rotated to 90
degrees, the user can place the child in
this position, but he/she cannot use this angle
during driving( see picture 3)
40-105cm
picture 1 picture 2
a
picture 3
10
