ABOUT THE PROJECTOR
This projector can receive high-definition video signals and composite video signals,
and supports the input and output of stereo audio signals. Refer to the figure below
to connect the projector and other audio equipment according to your needs:
IR Receiver
1
Lens
2
Power Socket
3
IR Receiver
4
Headphone Jack
5
HDMI1 Port
6
7 Removable Dust Cover
8
USB Port
Note: Press the dust net lightly and it will pop out for easy cleaning.
3
1 2
12
7
3
13 14
AV Port
9
HDMI2 Port
10
Speaker
11
Cooling Vent
12
Focus
13
Keystone
14
15 Cooling Vent
8 9
10 11
4 5 6
15
