Rear wheel tread adjustment
Rear wheel position can be changed to adjust the rear wheel tread in accordance
with the tilling width.
1. Set the tiller on a firm level ground and hold it securely by placing a suitable
block under the transmission case and raising the rear wheels off the ground.
2. Remove the retaining pin and wheel pin, and remove the rear wheels.
3. Reverse and slide the rear wheels onto the wheel shaft.
4. Insert the wheel pin by aligning the pin holes and install the retaining pin. Be
sure to install the right and left rear wheels in the symmetrical positions.
WIDE TREAD
RETAINING PIN
WIDE TREAD:
500 mm (19.7in)
WHEEL PIN
NARROW TREAD
REAR WHEEL
RETAINING PIN
NARROW TREAD:
300 mm (11.8in)
