Functional Description and Specifications

Intended Use
The Nemo Grabo is a fully portable electric vacuum grabo, in-
tended to lift, move, and place everything from tiles and drywall
to furniture and large appliances.
The Grabo features up to 170 kg (375 lbs) of grabbing force, and
can secure to almost any surface, enabling you to handle un-
wieldly loads quicker and more safely than ever before, all while
minimizing the risk of damage to expensive materials.
Packing List
Your Nemo Grabo is packaged together with the following
accessories:
• Two battery packs
(one attached to the grabo and another spare)
• Battery charger
• Replacement rubber foam seal
• Lifting strap
A carrying case can be purchased separately.
2

Technical Specifications

Nemo Grabo
Battery voltage 14.8V Li-ion
Battery cell specification 2.2Ah
Rated power 16W
Dimensions 297 x 181 x 115mm
(11.7 x 7.1 x 4.5 inches)
Net weight (with battery) 1.5kg (3.3lbs)
Working temperature 0°C - 60°C (30°F - 140°F)
Working time (full charge) 1.5 uur
Max Lifting Force
(look at page 27 for P. to p. lifting force conversion)
Perpendicular Hold
Glass
Metal
Plastic
Wood
Ceramic Tile
Rough Concrete
Dry Wall
Rough Slate

Battery Charger

Model XVE-1680150
Charging output voltage DC16.8V 1.5A
Charging input voltage 100V-240VAC 50/60Hz 1.5A max
Parallel Hold
170kg 120kg
110kg 110kg
100kg 100kg
100kg 65kg
170kg 120kg
80kg 80kg
75kg 65kg
80kg 80kg
3
