Packwise Smart Cap Montageanleitung Seite 6

Packwise Smart Cap consists of
1x Sensor (a)
1x O-ring (b)
1x Locking plate with adhesive pad (c)
All components are delivered packaged together in an
unassembled state. After mounting, the sensor should
only be detached from the locking plate if necessary.
For correct mounting, read "Preparation: Assembling
sensor and locking plate" on the following page.
10
a
b
c
Preparation: Assembling sensor and
locking plate
1) Insert O-ring into the locking plate.
2) Place sensor on locking plate (as displayed on
picture below).
3) Press firmly and snap in sensor.
NOTE: Make sure sensor has snapped on both sides.
11
