INSTALLATION STEPS

INSTALL THE FRAME
Fasten the front stabilizer (l2) on the frame with bolts (21) , washers (23)and
acorn nuts (22)with a open-end spanner (26); then fasten the rear stabilizer(13)
on the frame by the same way.
26
22
12
23
13
21
INSTALL THE CUSHION
Fasten the seat riser (9) on the frame with ball pin (7), then fasten the saddle(11)
to the seat riser with seat retainer (10). Tighten the screw on the seat with
washer and plum bolt (8) which pre- install into the seat retainer. The distance
between the front and back of the seat can be adjusted.
11
10
8
9
7
6
