SISTEMATICA EASY Benutzerhandbuch Seite 23

12 CONDUCTOR CABLE: XCBLSEC12RXX_L
COLOUR OF EACH
PIN
CONDUCTOR
RED B8
BLACK B1
WHITE A8
GREEN/WHITE A7
GREEN B7
YELLOW C7
GREY A6
PINK B6
ORANGE A5
VIOLET B5
BROWN C8
BLUE C1
STD CNTR 8 CNTR 20
+BATT
-BATT
MO
EO
OUT1
OUT2
OUT3
OUT4
OUT5
OUT6
+BATT
-BATT
17 CONDUCTOR CABLE: XCBLSEC17RXX_L
COLOUR OF EACH
PIN
CONDUCTOR
RED B8
BLACK B1
WHITE A8
GREEN/WHITE A7
GREEN B7
YELLOW C7
GREY A6
PINK B6
ORANGE A5
VIOLET B5
GREY/WHITE A4
RED/WHITE B4
VIOLET/WHITE C2
BROWN/WHITE C4
YELLOW/WHITE C3
BROWN C8
BLUE C1
STD CNTR 8 CNTR 20
+BATT
-BATT
MO
EO
OUT1
OUT2
OUT3
OUT4
OUT5
OUT6
OUT7
OUT8
IN DIG
CANL
CANH
+BATT
-BATT
23
