CONTROLS
1
4
5
6
7

REAR PANEL

DESIGNATION
1. Turntable
2. Drive Hub
3. Turntable Hub
4. Voltage Selector
5. ON/OFF Switch for Turntable Illumination
6. START/STOP Button
7. 33/45 Selector
8. Switch for Stylus Illumination
9. Pitch Fader
10. Headshell with Pick-Up System
11. Pick-Up Arm
12. Pick-Up Rest
13. Pick-Up Lift
14. Anti-Skating Wheel
15. Balancing Weight Scale
16. Balancing Weight
17. Audio Output Cable (RCA) + GND Grounding Cable
18. Mains Connection
2
3
10
8
17
16
15
14
13
12
11
9
18
7
