3. Technical data

Model
Energy efficiency class (EU 1060/2010)
Energy efficiency class (EU 2019/2016)
Cool box power supply
Mains adapter power supply
Usable volume
Energy consumption
Ambient temperature
Cooling performance
Noise level
USB charge connection
Refrigerant quantity
Refrigerant
Cool box protection class
Degree of protection / protection class of mains adapter IP20 / II
Length of the DC (12 / 24 V) connection cable
Length of the AC (230 V) connection cable
Dimensions (L x W x H)
Net weight
Item no.

4. Scope of delivery

Included in the product scope of supply are:
A compressor cooler, with 12 & 24 volt connection cable, mains adapter for 230 V~ connection, storage basket
and operating instructions.
If possible, retain the packaging until your guarantee has expired. Dispose of packing materials in an environmen-
tally friendly manner.

5. Commissioning

Before using the device for the first time, it must be placed upright on a horizontal surface for at least 6
hours. Always place the cooling unit on the floor. If the cooling unit is operated in any other orientation,
the unit may be damaged. It is possible to operate the device at an angle of max. 30° for short periods
of time. If the device has fallen over or been stored on its side, it must also be placed upright for at
least 6 hours before it is put into operation.
5.1 Connecting the compressor cooler
12 V / 24 volts (DC) ➤ Plug the DC connection cable into the DC socket and connect it to a DC receptacle.
230 volt (AC) ➤ Plug the supplied power supply unit into a 230 V~ socket and connect it to the cooler.

5.2 Operating settings

Switching on/off
•
Connect the cooler to the desired power supply.
•
Press the ON/OFF button to start the device.
•
Press the ON/OFF button again to switch the device off.
Setting the target temperature
•
Press the + (for warmer) or - (for colder) button to set the target temperature to your preference. The de-
vice adopts the last displayed value as the target temperature.
Changing the operating mode (Eco mode & Max mode)
•
ECO mode (energy saving mode) / MAX mode (fast cooling mode)
ICEBOX 40
A++
E
12 V (DC), 24 V (DC), 230 V (AC) via mains adapter
100 – 240 V~ 50/60 Hz (1.2 - 0.5 A)
40 l
78 kWh/year
+10 – + 43 °C (SN/N/ST/T)
-20 – + 20 °C
45 dB
5 V / 1 A
0.04 kg
R1234yf
III (safety extra-low voltage)
3.5 m
2.1 m
650 x 375 x 427 mm
14 kg
68061
