ITEM-NR.
DIMENSIONS
POWER CONSUMPTION
COLOR TEMPERATURE
BEAM ANGLE
INPUT VOLTAGE
WORKING TEMPERATURE
POWER FACTOR
COLOR RANDERING INDEX
FREQUENCY
Press the „ON/OFF" button and the light switches to constant on/
off mode, the sensor is deactivated.
Press the „M/R" button briefly to activate the sensor.
Short press the „M/R" button: all parameters return to the last
settings.
Long press of the „M/R" button: all parameters are reset to factory
settings.
Stand-by dim level
Set up stand-by dim level: 10% / 30%
Detection Area
Set up detection area: 25% / 50% / 100%
Short press „DIM+ / DIM-" button to transmit dimming signal. The
brightness of the lamp adjust at 5% per unit, from 50% to 100%.
Independent of POWERselect.
Stand-by period
Set up stand-up time: 0s / 1min / 30min / +∞
Daylight sensor
Set up daylight threshold: 5lux / 10lux / 50lux / disable
Hold time
Set up hold time: 5s / 1min / 5min / 10 min
2822-840120
1540 x 100 x 80 mm
38 W
4000 K
120°
220 – 240 V AC
-20 °C – +45 °C
0,90
> 82
50/60 Hz
9
