LED and Interface Explanation
Data/PoE PoE injector got 100-240V power input.
Mode A 1/2 (-) 3/6 (+) Power input
Mode B 4/5 (+) 7/8 (-) Power output
AC Socket Connect with AC cable
PoE/DATA Connect to the camera with UTP cable CAT5E or CAT6 supply power.
DATA/IN Connect to the Ethernet device with CAT5E or CAT6 UTP cable to
transmit data.
Specifications
Model
Output voltage
PoE power
Standard
Pin Polarity
Data rates
Input power
requirements
Dimensions
Indicators
Connectors
Protection
Environmental
conditions
POE300
53V DC
Max. 30W & 60W
802.3af/at/bt
1/2 (-), 3/6 (+), 4/5 (+), 7/8 (-)
10/100/1000 Mbps
AC input voltage: 100 to 240 V AC
AC input current: 0.5A 100-240 V AC
AC frequency: 50-60 Hz
168×73.5×44 mm
System indicator: AC power
User indicator: Channel power
Shielded RJ-45, EIA 568A and 568B
Overcurrent protection
Overload protection
Overvoltage protection
Anti-interference protection
Operating temperature: 0 to 40 °C
Operating humidity: max. 85%
Storage temperature: -40 to 60 °C
