Icy Box IB-CH504-QN Handbuch Seite 6

Tip No Voltage
M1
15 V (120 W
Max)
M2 16 V (120 W
Max)
M3
16 V (120 W
Max)
M4
18.5 V (120
W Max)
M5
19 V (120 W
Max)
M6 19 V (120 W
Max)
M8
19.5 V (120
W Max)
M15
19 V (120 W
Max)
Manual IB-CH504-QN
Tip size Fit for following models
6.3x3.0 mm Toshiba: 15 V/3 A, 15 V/4 A, 15 V/5 A, 15 V/6 A, 15 V/8 A
Nec: 15 V/6 A, 15 V/8 A etc.
5.5x2.5 mm IBM, Lenovo: 16 V/3.36 A, 16 V/3.5 A, 16 V/4.5 A
6.5x4.4 mm Fujitsu: 16 V/3.36 A, 16 V/3.75 A
Sony: 16 V/3.42 A, 16 V/3.75 A, 16 V/4 A etc.
4.8x1.7 mm HP/Compaq: 18.5 V/1.1 A, 18.5 V/2.7 A, 18.5 V/3.5 A,
18.5 V/3.8 A, 18.5 V/4.74 A, 18.5 V/4.9 A, 18.5 V/6.5 A etc.
5.5x2.5 mm Acer: 19 V/3.42 A, 19 V/4.74 A, 19 V/6.3 A
Asus: 19 V/3.42 A, 19 V/4.74 A
Detla: 19 V/2.64 A, 19 V/3.16 A, 19 V/3.42 A, 19 V/4.74 A, 19 V/6.3 A
Gateway: 19 V/2.64 A, 19 V/3.16 A, 19 V/3.42 A, 19 V/4.74 A
IBM: 19 V/3.16 A, 19 V/4.2 A
Nec: 19 V/4.74 A, 19V/6.3 A
Toshiba: 19 V/3.42 A, 19 V/3.95 A, 19 V/4.74 A, 19 V/6.3 A
Hasee: 19 V/3.42 A, 19 V/4.74 A
Lenovo: 19 V/4.74 A
Liteon: 19 V/3.16 A, 19 V/3.42 A, 19 V/3.95 A, 19 V/4.74 A, 19 V/6.3 A etc.
5.0x3.0 mm Samsung: 19 V/2.1 A, 19 V/3.16 A, 19 V/4.74 A etc.
6.5x4.4 mm Sony: 19.5 V/2.15 A, 19.5 V/3 A, 19.5 V/3.9 A, 19.5 V/4.1 A, 19.5
V/4.74 A, 19.5 V/5.13 A, 19.5 V/6.15 A etc.
5.5x1.7 mm Acer: 19 V/3.16 A, 19 V/3.42 A, 19 V/4.74 A
Liteon: 19 V/3.16 A, 19 V/3.42 A, 19 V/4.74 A etc.
