Application
Intelligent Charging!
The IB-CH504-QN has a new intelligent chipset that automatically communicates with any connected
mobile-device. The charging-ports identify the specific charging rate of any mobile-device and
charges them with their specific maximum charging speed.
USB charging ports
Note: It is recommended to use the original USB charging cable of your mobile device for charging.
1. Connect the power cable with the IB-CH504-QN and power outlet before usage.
2. Please connect devices to the corresponding USB output of the IB-CH504-QN.
3. The IB-CH504-QN will protect the chipset by intelligent overcharging/overloading monitoring.
Universal notebook charging port
Note: The universal notebook charging port does not support the reversible orientation and cable
insert. The information about the electric specification of your device is usually shown in the manual.
1. Connect the power cable with the IB-CH504-QN and power outlet before usage.
2. Please connect your device to the notebook charging port of the IB-CH504-QN via the
delivered charging cable by using the right DC tip, accordingly to the charging requirement of
your device (see the table as shown as below):
Manual IB-CH504-QN
IB-CH504-QN
Notebook
USB Type-C ™
2x USB Type-A
1x USB Type-A,
QC 2.0
