Package content
1x IB-CH504-QN, 1x power cable, 1x Notebook charging cable,
8x different DC tips, 1x quick installation guide
Main Features
• Supports charging of the most leading notebook brands
• Compatible with most smartphones and tablets chargeable via USB (5 V)
• One USB port supports QC 2.0 specification for high speed charging
• Intelligent chipset automatically recognizes the charging mode
• Safe use by overvoltage and short circuit protection
• Total Output: 85 W
General information
The All-in-One universal notebook & USB 85 W charger charges up to four USB-powered devices
and one notebook simultaneously and automatically detects maximum power output for each connec-
ted device for optimal charging efficiency.
Overview
1 2
1. 2x USB Type-A: 5 V up to 2.4 A
2. 1x QC 2.0 USB Type-A: 5 V/3 A, 9 V/2 A, 12 V/1.5 A
3. 1x USB Type-C™: 5 V up to 3 A
4. 1x notebook charging port: 15 V/4.33 A – 19.5 V/3.25 A (up to 65 W)
5. Power jack for internal power supply
Manual IB-CH504-QN
3 4 5
