Programming TV control buttons
1. Place the tuner remote and the TV remote towards each other, at around 4 cm
distance.
2. Press and hold the SET button, until the red LED glows stronger.
3. On the tuner remote, press one of the programmable buttons (in the TV CONTROL
frame).
4. Press the corresponding button on the TV remote a couple of times.
5. Press the SET button, to exit the pairing mode.
6. The function is assigned to the button. If the button does not work, try repeating
steps above.
CONNECTING
• To get high resolution, connect the tuner to the TV with an HDMI cable.
• To get standard resolution, connect the tuner to the TV with a SCART cable.
TV
Antenna
14
Power
supply
EN
BATTERY INSTALLATION
1. Open the battery compartment.
2. Place two AA batteries, according to polarity.
3. Close the battery compartment cover.
Notes:
• Do not mix old and new batteries.
• If the remote is not going to be used in a long time, store
it without batteries inside.
• Protect the remote from direct sunlight and other heat
sources.
OPERATION
1. To enter the Main menu, press the MENU button.
2. To navigate the menu, use volume and channel buttons. To confirm choices, press
the OK button. To exit a menu, press the Exit button.
INITIAL STARTUP
If the device is turned on for the first time (or the factory reset has been performed),
the setup screen will be shown on the screen.
1. Select language, country and if the antenna is powered.
2. Press the Begin button. The tuner will now search for available channels.
MAIN MENU
Program
Channel edit: Allows for blocking, deleting, skipping, changing channel names, and
managing favorite channels list. To preview selected channel, press the OK button.
Press one of the buttons, to go to the channel edit mode:
• Press the 1 button to enable channel deleting mode. Select channels that you want
to delete with the OK button, then press the EXIT button to delete these channels.
• Press the 2 button to enable moving channels mode. Select a channel that you want
to move with the OK button, then using the up and down button, move the channel
to new position. Press the EXIT button to save. Note: in the moving channels mode,
the LCN function should be off.
• Press the 3 button to enable skip channel mode. Select channels that you want to
skip with the OK button. Press the EXIT button to save.
• Press the 4 button to enable channel lock mode and input password (default:
000000). Select channels that you want to block with the OK button. Press the EXIT
EN
